Xerox WorkCentre 7132

January 2007
6-65
WorkCentre 7132
IOT NVM List
General procedures information
Reversion 4.0
752-186 Nominal RADC Target[K] 282 0~1023 RADC target value set up as the center
752-187 RADC Target[Y] 350 0~1023 RADC target value after various corrections
752-188 RADC Target[M] 350 0~1023 RADC target value after various corrections
752-189 RADC Target[C] 350 0~1023 RADC target value after various corrections
752-190 RADC Target[K] 350 0~1023 RADC target value after various corrections
752-195 RADC[Y] 0 0~1023 RADC value calculated from ADC-related detection values
752-196 RADC[M] 0 0~1023 RADC value calculated from ADC-related detection values
752-197 RADC[C] 0 0~1023 RADC value calculated from ADC-related detection values
752-198 RADC[K] 0 0~1023 RADC value calculated from ADC-related detection values
752-203 TRC RADC Target[Y][A] 680 0~1023 Target RADC for tone correction
752-204 TRC RADC Target[Y][B] 385 0~1023 Target RADC for tone correction
752-205 TRC RADC Target[Y][C] 915 0~1023 Target RADC for tone correction
752-206 TRC RADC Target[M][A] 605 0~1023 Target RADC for tone correction
752-207 TRC RADC Target[M][B] 340 0~1023 Target RADC for tone correction
752-208 TRC RADC Target[M][C] 910 0~1023 Target RADC for tone correction
752-209 TRC RADC Target[C][A] 645 0~1023 Target RADC for tone correction
752-210 TRC RADC Target[C][B] 400 0~1023 Target RADC for tone correction
752-211 TRC RADC Target[C][C] 915 0~1023 Target RADC for tone correction
752-212 TRC RADC Target[K][A] 475 0~1023 Target RADC for tone correction
752-213 TRC RADC Target[K][B] 165 0~1023 Target RADC for tone correction
752-214 TRC RADC Target[K][C] 845 0~1023 Target RADC for tone correction
752-215 TRC RADC[Y][A] 0 0~1023 RADC value for tone correction
752-216 TRC RADC[Y][B] 0 0~1023 RADC value for tone correction
752-217 TRC RADC[Y][C] 0 0~1023 RADC value for tone correction
752-218 TRC RADC[M][A] 0 0~1023 RADC value for tone correction
752-219 TRC RADC[M][B] 0 0~1023 RADC value for tone correction
752-220 TRC RADC[M][C] 0 0~1023 RADC value for tone correction
752-221 TRC RADC[C][A] 0 0~1023 RADC value for tone correction
752-222 TRC RADC[C][B] 0 0~1023 RADC value for tone correction
752-223 TRC RADC[C][C] 0 0~1023 RADC value for tone correction
752-224 TRC RADC[K][A] 0 0~1023 RADC value for tone correction
752-225 TRC RADC[K][B] 0 0~1023 RADC value for tone correction
752-226 TRC RADC[K][C] 0 0~1023 RADC value for tone correction
752-253 Nominal TRC RADC Target[Y][B] 385 0~1023 TRC_RADC target value set up as the center
752-254 Nominal TRC RADC Target[M][B] 340 0~1023 TRC_RADC target value set up as the center
752-255 Nominal TRC RADC Target[C][B] 400 0~1023 TRC_RADC target value set up as the center
752-256 Nominal TRC RADC Target[K][B] 165 0~1023 TRC_RADC target value set up as the center
752-299 SW DispMode 0 0~2 Switch that selects Disp Mode (0: ADC+ICDCdisp 1: ICDCdisp 2: Timerdisp)
752-301 Timer Disp time[Y] 5 0~255 Timer Disp set time (in steps of 10ms)
752-302 Timer Disp time[M] 5 0~255 Timer Disp set time (in steps of 10ms)
752-303 Timer Disp time[C] 5 0~255 Timer Disp set time (in steps of 10ms)
Table 9 Process Control
Chain-Link Name Default Range Description
