Xerox WorkCentre 7132

January 2007
6-66
WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
752-304 Timer Disp time[K] 5 0~255 Timer Disp set time (in steps of 10ms)
752-441 SW LD Control 0 0~1 Switch that sets LD Control to ON/OFF
(0: LDControl ON 1: LD Control OFF)
752-443 SW DeveBias Control 0 0~1 0: Vbias controlled 1: Vbias not controlled (delta Vbias=0)
752-444 LD Light qty when LD Control is OFF[Y] 420 0~1023 LD light quantity with electric potential control Off
752-445 LD Light qty when LD Control is OFF[M] 420 0~1023 LD light quantity with electric potential control Off
752-446 LD Light qty when LD Control is OFF[C] 420 0~1023 LD light quantity with electric potential control Off
752-447 LD Light qty when LD Control is OFF[K] 420 0~1023 LD light quantity with electric potential control Off
752-448 LD light qty[Y] 420 0~1023 Ideal LD light quantity calculated from delta LD light quantity
752-449 LD light qty[M] 420 0~1023 Ideal LD light quantity calculated from delta LD light quantity
752-450 LD light qty[C] 420 0~1023 Ideal LD light quantity calculated from delta LD light quantity
752-451 LD light qty[K] 420 0~1023 Ideal LD light quantity calculated from delta LD light quantity
752-460 Flag LD Light qty Limit[Y] 0 0~2 0: within upper & lower limits 1: lower limit 2: upper limit
752-461 Flag LD Light qty Limit[M] 0 0~2 0: within upper & lower limits 1: lower limit 2: upper limit
752-462 Flag LD Light qty Limit[C] 0 0~2 0: within upper & lower limits 1: lower limit 2: upper limit
752-463 Flag LD Light qty Limit[K] 0 0~2 0: within upper & lower limits 1: lower limit 2: upper limit
752-464 Warn LD Light qty[Y] 0 0~1 0: within upper & lower limits 1: upper or lower limit
752-465 Warn LD Light qty[M] 0 0~1 0: within upper & lower limits 1: upper or lower limit
752-466 Warn LD Light qty[C] 0 0~1 0: within upper & lower limits 1: upper or lower limit
752-467 Warn LD Light qty[K] 0 0~1 0: within upper & lower limits 1: upper or lower limit
752-705 Flag Empty Detection Status[Y] 0 0~3 0: Normal 1: PreNear 2: NearEmpty 3: Empty
752-706 Flag Empty Detection Status[M] 0 0~3 0: Normal 1: PreNear 2: NearEmpty 3: Empty
752-707 Flag Empty Detection Status[C] 0 0~3 0: Normal 1: PreNear 2: NearEmpty 3: Empty
752-708 Flag Empty Detection Status[K] 0 0~3 0: Normal 1: PreNear 2: NearEmpty 3: Empty
752-789 SW PreNear 0 0~1 Switch that selects whether or not PreNear should be displayed. (1: not displayed 2: displayed)
752-790 PreNear Threshold[Y] 4032 0~65535 PreNear Threshold calculated from ICDC for a remaining toner ratio of 0%
752-791 PreNear Threshold[M] 3750 0~65535 PreNear Threshold calculated from ICDC for a remaining toner ratio of 0%
752-792 PreNear Threshold[C] 4032 0~65535 PreNear Threshold calculated from ICDC for a remaining toner ratio of 0%
752-793 PreNear Threshold[K] 11533 0~65535 PreNear Threshold calculated from ICDC for a remaining toner ratio of 0%
752-794 Flag PreNear[Y] 0 0~1 0: Normal status 1: PreNear and afterward
752-795 Flag PreNear[M] 0 0~1 0: Normal status 2: PreNear and afterward
752-796 Flag PreNear[C] 0 0~1 0: Normal status 3: PreNear and afterward
752-797 Flag PreNear[K] 0 0~1 0: Normal status 4: PreNear and afterward
752-812 Toner Level[Y] 100 0~100 a ratio of toner remaining in Toner Cartridge
752-813 Toner Level[M] 100 0~100 a ratio of toner remaining in Toner Cartridge
752-814 Toner Level[C] 100 0~100 a ratio of toner remaining in Toner Cartridge
752-815 Toner Level[K] 100 0~100 a ratio of toner remaining in Toner Cartridge
752-825 Toner Level 0% ICDC[Y] 4743 0~65535 ICDC total value corresponding to 0% of remaining toner
752-826 Toner Level 0% ICDC[M] 4412 0~65535 ICDC total value corresponding to 0% of remaining toner
752-827 Toner Level 0% ICDC[C] 4743 0~65535 ICDC total value corresponding to 0% of remaining toner
752-828 Toner Level 0% ICDC[K] 13568 0~65535 ICDC total value corresponding to 0% of remaining toner
Table 9 Process Control
Chain-Link Name Default Range Description
