Chain 760-xxx Registration Control
Table 10 Process Control
Chain-
Link
Name Default Range Description
753-001 SW ADC Tone Correction 0 0~1 Switch that sets ADC Tone Correction to ON/OFF
0: ON
1: OFF
753-002 SW TRC Adjust 0 0~1 Switch that sets TRCadjust to ON/OFF
0: TRCadj_ON
1: TRCadj_OFF
Table 11 Registration Control
Chain-Link Name Default Range
Read/
Write Description
760-001 Polygon Synchronic Correction Switch 0 0~1 RW Polygon Sync Correction Switch
0: ON
1: OFF
760-002 Offset Correction Switch 0 0~1 RW Offset Correction Switch
0: ON
1: OFF
760-003 Learn Value Use Switch 0 0~1 RW Learning-Result Using Switch
0: Learned value
1: NVM value
760-004 K-Speed Correction Switch 0 0~1 RW Belt Speed Up Correction Switch
0: ON
1: OFF
760-005 K-Speed Correction Learn Value Use Switch 0 0~1 RW Switch sets whether to use learning result in correcting Belt speed to speed it up.
0: Learned value
1: NVM value
760-006 GAPy 0 0~65535 R Phase difference between TR0 and SOS: GAPy
[1/50 micro s]
760-007 GAPm 0 0~65535 R Phase difference between TR0 and SOS: GAPm
[1/50 micro s]
760-008 GAPc 0 0~65535 R Phase difference between TR0 and SOS: GAPc
[1/50 micro s]
760-009 GAPk 0 0~65535 R Phase difference between TR0 and SOS: GAPk
[1/50 micro s]
760-014 BL Thresh 90 0~500 RW Learn Mode Execution Count switching threshold
[100PV]
760-015 BL Cycle1 15 0~70 RW Learn Mode Execution Count Value 1
[100PV]
760-016 BL Cycle2 30 0~100 RW Learn Mode Execution Count Value 2
[100PV]
760-017 Belt Length Correction Switch 0 0~1 RW Belt Cycle Length Correction Switch
[0: On 1: Off]
