Xerox WorkCentre 7132

January 2007
6-69
WorkCentre 7132
IOT NVM List
General procedures information
Reversion 4.0
760-052 Y13 100 0~200 RW Offset Correction Coefficient: Y13
760-053 Y14 53000 0~10000
0
RW Offset Correction Coefficient: Y14
760-054 K1 43700 0~10000
0
RW Offset Correction Coefficient: K1
760-055 K2 62 0~200 RW Offset Correction Coefficient: K2
760-056 K3 50000 0~10000
0
RW Offset Correction Coefficient: K3
760-057 K4 34247 0~10000
0
RW Offset Correction Coefficient: K4
760-058 K5 85 0~200 RW Offset Correction Coefficient: K5
760-059 K6 85 0~200 RW Offset Correction Coefficient: K6
760-060 K7 100 0~200 RW Offset Correction Coefficient: K7
760-061 K8 50000 0~10000
0
RW Offset Correction Coefficient: K8
760-062 K9 31095 0~10000
0
RW Offset Correction Coefficient: K9
760-063 K10 85 0~200 RW Offset Correction Coefficient: K10
760-064 K11 85 0~200 RW Offset Correction Coefficient: K11
760-065 K12 100 0~200 RW Offset Correction Coefficient: K12
760-066 K13 50000 0~10000
0
RW Offset Correction Coefficient: K13
760-077 K14 74 0~200 RW Offset Correction Coefficient: K14
760-078 K15 75 0~200 RW Offset Correction Coefficient: K15
760-079 K16 100 0~200 RW Offset Correction Coefficient: K16
760-080 K17 43000 0~10000
0
RW Offset Correction Coefficient: K17
760-081 K-speed-offset start timing 12 4~15 RW Time (100msec)from Belt Home detection that triggers plotting an image in K to the start of
modulating IBT Belt speed.
760-082 K-speed-offset end timing 3700 300~370
0
RW Time (msec) from Belt Home detection that triggers plotting an image in K to the end of
modulating IBT Belt speed
760-083 K-speed-offset value 20264 20193~2
0274
RW The double of this NVM value shall be an actual division ratio in speed modulation for K.
760-085 Slope of Low Brightness 261 0~511 RW Low-light-intensity-area regi correction gradient
760-086 Slope of High Brightness 69 0~511 RW High-light-intensity-area regi correction gradient
760-087 Intercept of Low Brightness 6528 0~65535 RW Low-light-intensity-area Y intercept
760-088 Intercept of High Brightness 1723 0~6535 RW High-light-intensity-area Y intercept
760-089 LD-Volume Adjust Switch 0 0~1 RW Light Qty Regi Correction S/W
0: On
1: Off
760-090 Regi-Control Change Point 430 250~880 RW Control Gradient changing point
760-091 Y15 87 0~200 RW Y15
Table 11 Registration Control
Chain-Link Name Default Range
Read/
Write Description
