Xerox WorkCentre 7132

January 2007
6-70
WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
Chain 762-xxx Developer
760-092 Y16 96 0~200 RW Y16
760-093 Y17 100 0~200 RW Y17
760-094 Y18 55000 0~10000
0
RW Y18
760-095 Y-Speed Correction Switch 0 0~1 RW Y Belt Speed Up Correction Switch
0: On
1: Off
760-096 Y-Speed Correction Learn Value Use Switch 0 0~1 RW Switch sets whether to use learning result in correcting Y Belt speed to speed it up.
0: Learned value
1: NVM value
760-097 Y-speed-offset start timing 22 20~30 RW Time (100msec)from Belt Home detection that triggers plotting an image in Y to the start of
modulating IBT Belt speed
760-098 Y-speed-offset value 20302 20274~2
0355
RW The double of this NVM value shall be an actual division ratio in speed modulation for Y.
760-100 K-Speed Two Step Correction Switch 0 0~1 RW 2-step speed modulation for K
0: On
1: Off
760-101 K-speed Two Step offset value 20235 20139~2
0274
RW 2-step Speed Modulation division ratio for K
760-102 K-Two Step-speed-offset start timing 2600 2000~37
00
RW 2-step speed modulation starting point for K
[msec]
760-103 TR0 seal dirt error counter 0 0~255 RW Logs how many times dirt has been detected on the effective area of TR0 sticker.
760-104 TR0 seal dirt warning counter 0 0~255 RW Logs how many times dirt on TR0 sticker has been detected.
760-105 Belt Home Position Too Long Fail threshold 2354 2337~45
30
RW Threshold for detecting Broken Belt Fail
Table 11 Registration Control
Chain-Link Name Default Range
Read/
Write Description
Table 12 Deve
Chain-Link Name Default Range Read/Write Description
762-001 BIAS_DC_ON 67 1~145 RW DC BIAS ON Timing (67 Steps before)
762-002 BIAS_AC_ON 67 1~145 RW AC BIAS ON Timing (67 Steps before)
762-003 BIAS_DC_OFF 67 1~145 RW DC BIAS OFF Timing (67 Steps after)
762-004 BIAS_AC_OFF 67 1~145 RW AC BIAS OFF Timing (67 Steps after)
762-005 DEVE_MOT_ON 200 0~1000 RW DEVE_MOT ON Timing (300ms before image)
762-006 DEVE_MOT_OFF 1 1^145 RW DEVE_MOT OFF Timing (1 Step after)
762-007 ROT_MOT_ON 10 0~500 RW ROTARY MOTOR ON Signal ON timing (10ms before HI/LOW signal)
762-008 ROT_MOT_OFF 10 0~500 RW ROTARY MOTOR ON Signal OFF timing (10ms after HI/LOW signal)
762-009 ROT_MOT_HL_ON 30 0~500 RW ROTARY HI/LOW Signal ON timing (30ms before DEVE CLK)
762-010 ROT_MOT_HL_OFF 200 0~500 RW ROTARY HI/LOW Signal OFF timing (200ms after DEVE CLK)
762-011 FIRST_ROT_TIME_FC 693 0~2000 RW the timing of starting rotating Rotary when FC cycles up
(693ms before image)
