Xerox WorkCentre 7132

January 2007
6-71
WorkCentre 7132
IOT NVM List
General procedures information
Reversion 4.0
762-012 FIRST_ROT_TIME_BW 693 0~2000 RW the timing of starting rotating Rotary when BW cycles up
(693ms before image)
762-014 ROT_MOT_TIME_END 10 0~500 RW the timing of starting rotating Rotary when the M/C cycles down (10ms after the
trail edge of image)
762-015 Home Back Wait Time 500 0~2000 RW Wait Time between Exchange Position and Back Home
(500ms after the instruction)
762-016 ROTARY_POSITION 0 0~4 RW 0: Home
1: Kex
2: Yex
3: Mex
4: Cex
762-017 ESCAPE_INT_TIME 1700 0~3000 RW Rest Time (1700ms) in Kesc
762-022 ESCAPE BIAS DC 100 0~1000 RW Bias DC Value (100V) for generating band for a color that passes the develop-
ment position
762-023 BW_TRICLE_START_WAIT 500 0~2000 RW Wait Time before starting the operation of trickling toner (500ms after the trail
edge of image)
762-024 BW_TRICLE_WAIT_TIME 1000 0~3000 RW Wait Time (1000ms) at the position trickling is done
762-025 BW_TRICLE_DISP_LIMIT 1500 0~5000 RW Total Dispense Time Threshold (15sec: in steps of 10ms) in continuous B/W in
order to do the operation of trickling
762-026 BW_TRICLE_DISP_TOTAL 0 0~5000 RW Total Dispense Time in continuous B/W in order to do the operation of trickling
during job
762-027 NVM_HOME_ADJ_Switch 0 0~1 RW 0: Adjustment Mode not executed
1: Adjustment Mode executed
762-028 NVM_HOME_ADJ_PULSE 33 0~65 RW HOME SENSOR Installing Position Correction Value (N)
762-029 NVM_ROTARY_FAIL_LIMIT 8 0~50 RW Home Position Fail Occurrence Threshold (F)
762-030 Deve_Bias_DC 570 0~1000 RW Deve Bias DC Value (Default: 600V)
762-031 Deve_Bias_AC_F 6250 0~10000 RW Deve Bias AC Frequency (Default: 6000Hz)
762-032 Deve_Bias_AC_PP 1000 0~2000 RW Deve Bias AC Vpeak-peak Value (Default: 1000V)
762-033 Deve_Bias_AC_Duty 65 0~100 RW Deve Bias AC Duty (Default: 65%)
762-034 CRUM R/W WAIT TIME 1 10 0~500 RW Wait Time (ms) before CRUM R/W
762-035 CRUM R/W WAIT TIME 2 10 0~500 RW Wait Time (ms) after CRUM R/W
762-036 HOME POSITION ANGLE 35 0~65 RW Home Position Angle Preset Value (H)
762-038 CRUM R/W WAIT TIME 5 30 0~500 RW CRUM R/W Escape Wait Time (ms)
762-039 BAND_DEVE_ROT_TIME_K 0 0~65535 RW Total Deve Drive Time for band generation K
762-040 BAND_DEVE_ROT_TIME_Y 0 0~65535 RW Total Deve Drive Time for band generation Y
762-041 BAND_DEVE_ROT_TIME_M 0 0~65535 RW Total Deve Drive Time for band generation M
762-042 BAND_DEVE_ROT_TIME_C 0 0~65535 RW Total Deve Drive Time for band generation C
762-043 BAND Cin 60 0~100 RW Band Cin (Default: 60%)
762-044 BAND COVERAGE LIMIT 75 0~1000 RW Threshold for Band Execution Judgment
762-045 BAND LENGTH 145 0~1000 RW Band Length Calculation standard value
762-046 Down Step Timing 1 247 0~1000 RW the timing of starting Step Down in Step Control (layout difference from BCR:
227ms+20ms)
762-047 Down Step Timing 2 50 0~500 RW In Step Down in Step Control, Vm 3 hours
Table 12 Deve
Chain-Link Name Default Range Read/Write Description
