Xerox WorkCentre 7132 Service Documentation

January 2007
6-80
WorkCentre 7132
IIT NVM List
Reversion 4.0
General procedures information
Chain 715-xxx IISS
711-218 Feed Out Sensor Act. Correction Coefficient - A9 59 0~255 0.01 Initial value 0.59 0.00~2.55, 0.01 increments
711-219 Feed Out Sensor Act. Correction Coefficient - B9 104 0~255 1 Initial value 104 0~255, 1 increments
711-270 ADF-IIT Combine Adjustment Value Data 1 0 0~255 - Adjustment Value Data 1 sent to IIT during ADF-IIT Combine.
711-271 ADF-IIT Combine Adjustment Value Data 2 0 0~255 - Adjustment Value Data 2 sent to IIT during ADF-IIT Combine.
711-272 ADF-IIT Combine Adjustment Value Data 3 0 0~255 - Adjustment Value Data 3 sent to IIT during ADF-IIT Combine.
711-273 ADF-IIT Combine Adjustment Value Data 4 0 0~255 - Adjustment Value Data 4 sent to IIT during ADF-IIT Combine.
711-274 ADF-IIT Combine Adjustment Value Data 5 0 0~255 - Adjustment Value Data 5 sent to IIT during ADF-IIT Combine.
711-275 ADF-IIT Combine Adjustment Value Data 6 0 0~255 - Adjustment Value Data 6 sent to IIT during ADF-IIT Combine.
711-276 ADF-IIT Combine Adjustment Value Data 7 0 0~255 - Adjustment Value Data 7 sent to IIT during ADF-IIT Combine.
711-277 ADF-IIT Combine Adjustment Value Data 8 0 0~255 - Adjustment Value Data 8 sent to IIT during ADF-IIT Combine.
711-278 ADF-IIT Combine Adjustment Value Data 9 0 0~255 - Adjustment Value Data 9 sent to IIT during ADF-IIT Combine.
711-279 ADF-IIT Combine Adjustment Value Data 10 0 0~255 - Adjustment Value Data 10 sent to IIT during ADF-IIT Combine.
711-280 ADF-IIT Combine Adjustment Value Data 11 0 0~255 - Adjustment Value Data 11 sent to IIT during ADF-IIT Combine.
711-281 ADF-IIT Combine Adjustment Value Data 12 0 0~255 - Adjustment Value Data 12 sent to IIT during ADF-IIT Combine.
711-282 ADF-IIT Combine Adjustment Value Data 13 0 0~255 - Adjustment Value Data 13 sent to IIT during ADF-IIT Combine.
711-283 ADF-IIT Combine Adjustment Value Data 14 0 0~255 - Adjustment Value Data 14 sent to IIT during ADF-IIT Combine.
711-284 ADF-IIT Combine Adjustment Value Data 15 0 0~255 - Adjustment Value Data 15 sent to IIT during ADF-IIT Combine.
711-297 Communication Fail Bypass 0 0~1 - 0: Disable Communication Fail Bypass 1: Enable Communication Fail Bypass
711-468 DADF Open/Close Life Count (upper digits) 3 0~65535 - 260K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-469 DADF Open/Close Life Count (lower digits) 63392 0~65535 -
711-470 DADF Document Feed Life Count (upper digits) 3 0~65535 - 200K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-471 DADF Document Feed Life Count (lower digits) 3392 0~65535 -
711-472 DADF Simplex and Duplex Document Feed Life
Count (upper digits)
13 0~65535 - 912K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
711-473 DADF Simplex and Duplex Document Feed Life
Count (lower digits)
60032 0~65535 -
711-474 Invert Solenoid Life Count (upper digits) 7 0~65535 - 500K * Life value may be changed in Counter Write Command. It cannot be written in
Chain Link setting.
Table 2 CVT DADF NVM LIST
Chain-Link Content Default Range 1 Count Meaning
Table 3 IISS
Chain-Link Content Default Range Meaning
715-007 PH_CL_Contone Scan Speed 0 0~1 Switches scan speed in Scan Photographic Printing Paper mode.
0: Half Speed mode
1: Normal Speed mode
715-017 IIT Fail Bypass 0 0~1 0: Fail Bypass Off, 1: Fail Bypass On
715-018 FAN Control Mode 0 0~1 0: Normal mode; 1: M/C for Multiple Stores mode
715-020 No. of APS 1 0~1 0: 1 APS, 1: 2 APS
