WorkCentre 7132
IIT NVM List
General procedures information
Reversion 4.0
715-022 Lamp Fan Fail Bypass 1 0~1 Existence or of Lamp Fan Fail Detection
0: Lamp Fan Fail Detection existent
1: Lamp Fan Fail Detection not existent
715-023 Lamp Fan On Time (Low Rotation) 15 0~60 Lamp Fan On at Low Speed time (in minute)
715-024 Lamp Fan Off Time 1 0~60 Lamp Fan Off time (in minute)
715-025 FL Timer Set 0 0~1 0: Standard FL Timer settings (30min rest/0.5sec On), 1: Condensation mode setting (Diag 715-
026, 715-027 timer settings apply)
715-026 Lamp ON Interval 30 0~60 Interval setting (unit: min)
715-027 Lamp ON Time 1 0~60 Lamp ON time setting (unit: sec)
715-030 IIT Failure Part Diagnosis 1 0~65535 Writing 1 allows starting diagnostics of a failed IIT part.
Reading this NVM after diagnostics is made on a failed part makes a certain presumed part No.
appear.
If a fail occurs during diagnostics of a failed part, Fail Code associated with the fail is logged in this
NVM and the diagnostics ends.
*Even if 1 is written, 1 is not actually done.
*If any value other than 1 is entered, the value becomes illegal.
715-050 Platen SS Registration Adjustment 100 16~184 Slow Scan Direction Regi Correction Value (0.036mm/increment), Factory Settings
715-051 Platen SS Reduce/Enlarge Adjustment 50 44~56 Slow Scan Direction Regi Correction Value (0.1%/increment), Factory Settings
715-052 Platen Glass Type 2 0~2 0: Platen model, 1: Belt DADF, 2: CVT, Factory Settings
715-053 Platen PRadjF 120 0~240 Fast Scan Direction Regi Correction Value (Dot), VLSS=PROMVLSS+(PRadjF-120)x2, Factory Set-
tings
715-056 CVT FS Offset Side1-1 (139.7-148) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-057 CVT FS Offset Rear Side2-1 (139.7~148) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-058 CVT FS Offset Side1-2 (182-194) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-059 CVT FS Offset Side2-2 (182-194) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-060 CVT FS Offset Side1-3 (203.2) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-061 CVT FS Offset Side2-3 (203.2) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-062 CVT FS Offset Side1-4 (210) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-063 CVT FS Offset Side2-4 (210) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-064 CVT FS Offset Side1-5 (214.9-215.9) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-065 CVT FS Offset Side2-5 (214.9-215.9) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-066 CVT FS Offset Side1-6 (254-257) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-067 CVT FS Offset Side2-6 (254-257) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-068 CVT FS Offset Side1-7 (266.7-267) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-069 CVT FS Offset Side2-7 (266.7-267) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-070 CVT FS Offset Side1-8 (279.4) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-071 CVT FS Offset Side2-8 (279.4) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-072 CVT FS Offset Side1-9 (297) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-073 CVT FS Offset Side2-9 (297) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-074 CVT FS Offset Side3-1 (139.7-148) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-075 CVT FS Offset Side4-1 (139.7-148) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
715-076 CVT FS Offset Side3-2 (182-194) 120 0~240 Fast Scan Direction Regi Correction Value (0.1mm/increment) in CVT. Factory Settings
Table 3 IISS
Chain-Link Content Default Range Meaning
