Page #1412 background image
January 2007
6-89
WorkCentre 7132
IIT NVM List
General procedures information
Reversion 4.0
715-725 DADF-P-Job RAE SS Not Detect Area 0 0~65535 Slow Scan Non-detection area Setup Value at Real Time AE for DADF model Platen job. Or, Slow
Scan Non-detection area Setup Value at Real Time AE for CVT job. BASE, HAEST, MAESST,
NAESS
715-726 DADF-D-Job RAE SS Not Detect Area 0 0~65535 Slow Scan Non-detection area Setup Value at Real Time AE for DADF model DADF job. BASE,
HAEST, MAESST, NAESS
715-780 Hue Angle B Starts 270 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-781 Hue Angle B Ends 320 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-782 Hue Angle G Starts 110 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-783 Hue Angle G Ends 200 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-784 Hue Angle R Starts 350 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-785 Hue Angle R Ends 60 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-786 Hue Angle Y Starts 60 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-787 Hue Angle Y Ends 120 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-788 Hue Angle M Starts 320 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-789 Hue Angle M Ends 360 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-790 Hue Angle C Starts 360 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-791 Hue Angle C Ends 360 0~360 1 degree increments. It means End to 360 and 0 to Start when Start > End.
715-800 IISS-DADF Communication Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-801 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-802 IISS-Controller Communication Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-803 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-804 DADF EEPROM Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-805 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-808 CRG Position Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-809 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-810 IISS LOGIC Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-811 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-814 Lamp Illumination Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-815 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-816 CRG Over Run Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-817 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-822 AGC Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-823 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-824 AOC Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-825 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-826 IPS PWBA Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-827 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-840 IPS PWBA Memory Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-841 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
715-856 IIT Hot Line Fail 0 0~65535 Accumulative Fail Counter value. (Write not permitted)
715-857 (Same as above) 0 0~65535 Accumulative Fail Counter value since it was last reset. (Write not permitted)
Table 3 IISS
Chain-Link Content Default Range Meaning
