Page #1411 background imageLoading...
Page #1411 background image
January 2007
6-88
WorkCentre 7132
IIT NVM List
Reversion 4.0
General procedures information
715-684 Default Value Color Balance Adjustment Level M
Color Medium density
4 0~8 Default Value Color Balance Adjustment Level M Color Medium density
715-685 Default Value Color Balance Adjustment Level M
Color High density
4 0~8 Default Value Color Balance Adjustment Level M Color High density
715-686 Default Value Color Balance Adjustment Level C
Color Low density
4 0~8 Default Value Color Balance Adjustment Level C Color Low density
715-687 Default Value Color Balance Adjustment Level C
Color Medium density
4 0~8 Default Value Color Balance Adjustment Level C Color Medium density
715-688 Default Value Color Balance Adjustment Level C
Color High density
4 0~8 Default Value Color Balance Adjustment Level C Color High density
715-689 CL Balance Def K / Low Density 4 0~8 Default Color Balance Adjustment Level K Color Low Density
715-690 CL Balance Def K / Medium Density 4 0~8 Default Color Balance Adjustment Level K Color Medium Density
715-691 CL Balance Def K / High Density 4 0~8 Default Color Balance Adjustment Level K Color High Density
715-702 PLTN/Belt FS Reduce/Enlarge Adjustment 50 0~100 Fine adjustment for Fast Scan Direction Reduce/Enlarge ratios. Specify within the range of 0 and
100 in increments of 1. The value indicates the fine adjustment with 0=-5%, 50=0% and 100=5% at
+/-5% (0.1% increments). (No adjustment in Factory Settings)
715-703 CVT FS Reduce/Enlarge Adjustment 50 0~100 Fine adjustment for Fast Scan Direction Reduce/Enlarge ratios. Specify within the range of 0 and
100 in increments of 1. The value indicates the fine adjustment with 0=-5%, 50=0% and 100=5% at
+/-5% (0.1% increments). (No adjustment in Factory Settings)
715-704 IPS Through Setting1 0 0~65535 IPS Through Setting 1. Force to skip Image Processing functions at memory sample scan. Change
a value at S/W & H/W DEBUG. Always set “0” in normal use. (Handle with care) --The usage is as
follows: Whether to execute/force to skip functions is assigned to each bit. However, you can spec
-
ify multiple bits at a time. [PF1]| [PF2],D'0: AES | BEXG_TH,D'1: DF39 | FSRE_TH,D'2: SSR |
SSR_TH,D'3: FSRE | NSP_TH,D'4: NSP | AER_TH,D'5: 4DLUT | TRC2_TH,D'6: 5AER |
ED_TH,D'7: 5MUL | SEL_TH,D'8: 5MWA | SEL2_TH,D'9: 4AER | (spare),D'10: 4MUL | (spare),D'11:
TRC | (spare),D'12: ED | (spare),D'13: DIRECT | (spare),D'14: (spare) | (spare),D'15: (spare) |
(spare) The specified bit value is: B'0: Unchanged, B'1: Forced to skip.
715-705 IPS Through Setting2 0 0~65535 IPS Through Setting 2 Set the 4DLUT Bypass mode.
This setting is valid only when IPS Bypass Setting1 is set to force skip 4DLUT.
Change a value at S/W & H/W DEBUG.
0: L*a*b* through from Y block
1: L*a*b* through from M block
2: L*a*b* through from C block
3: L*a*b* through from K block
4: L* through from YMCK block
5: a* through from YMCK block
6: b* through from YMCK block
7~65535: 0h output
715-720 Normal Density Text (BW Copy) 128 0~256 B/W COPY Text Normal Density Adjustment
715-721 High Density Text (BW Copy) 128 0~256 B/W COPY Text Darker 3 Density Adjustment
715-722 Normal Density Text (Scan/Fax) 128 0~256 Scan/FAX Text Normal Density Adjustment
715-723 High Density Text (Scan/Fax) 128 0~256 Scan/FAX Text Darker 3 Density Adjustment
715-724 PLTN RAE SS Not Detect Area 0 0~65535 Slow Scan Non-detection area Setup Value at Real Time AE for Platen model. BASE, HAEST,
MAESST, NAESS
Table 3 IISS
