Xerox WorkCentre 7132 Service Documentation

January 2007
6-87
WorkCentre 7132
IIT NVM List
General procedures information
Reversion 4.0
715-646 Color Contone Scan Background Color Suppres-
sion Level (Text/Photo)
0 0~4095 0: Strength Level 0 (Standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 or above: Level 0 (Standard)
0bit~3bit, Platen
4Bit~7Bit CVT or DADF machine
8Bit~11Bit CVT or DADF machine 2 Sided Copy
Tools and coupling
(Determine the Parameter Selection Level by adding the tool value (level 0 to 4) and the NVM Level
(level 0 to 4). If the total is Level 4 and above, it is determined as Level 4)
(* Also used by the PreIPS EAER_DAT Removal Level)
715-647 Color Contone Scan Background Color Suppres-
sion Offset Level (Text/Photo)
0 0~4095 0: Strength Level 0 (Standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 or above: Level 0 (Standard)
0bit~3bit, Platen
4Bit~7Bit CVT or DADF machine
8Bit~11Bit CVT or DADF machine 2 Sided Copy
715-648 Color Contone Scan Background Color Suppres-
sion Level (other than Text/Photo)
0 0~4095 0: Strength Level 0 (Standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 or above: Level 0 (Standard)
0bit~3bit, Platen
4Bit~7Bit CVT or DADF machine
8Bit~11Bit CVT or DADF machine 2 Sided Copy
(* Also used by the PreIPS EAER_DAT Removal Level)
715-649 Color Contone Scan Background Color Suppres-
sion Offset Level (other than Text/Photo)
0 0~4095 0: Strength Level 0 (Standard), 1: Strength Level 1, 2: Strength Level 2, 3: Strength Level 3, 4:
Strength Level 4, 5~15 or above: Level 0 (Standard)
0bit~3bit, Platen
4Bit~7Bit CVT or DADF machine
8Bit~11Bit CVT or DADF machine 2 Sided Copy
715-660 2 Sided AE Control Parameter Lower Limit Multi-
plication Coefficient
00~255
Used when calculating the HAE background value. 1/255 units. 255 indicates 1.
715-661 2 Sided AE Control Parameter Upper Limit Multi-
plication Coefficient
255 0~255 Used when calculating the HAE background value. Set as Upper limit multiplication coefficient +
Lower limit multiplication coefficient = 255 1/255 units. 255 indicates 1.
715-662 2 Sided AE Control Parameter Relative Margin
OFST
80~255The value added (or subtracted) when comparing the RAE background value and the HAE back-
ground value. When the value is large, Side2 cannot be selected.
715-663 2 Sided AE Control Parameter Background Level
Threshold Value LEVEL_N
16 0~255 The value used to compare with the HAE background value when selecting 2 Sided. 2 Sided is not
selected if this NVM is not reached for the HAE background value.
715-664 2 Sided AE Control Parameter Forced Selection 3 0~3 0: 2 Sided AE Control 1: Forced Side 1 (L0) Selection. 2: Force Side2 (L1) output
715-668 Dual Color Copy Control 0 0~1 Dual Color Copy Control. DLUT Parameter Selection Factor
0: Normal 1: Black (emphasize BW)
715-669 Control of Tracing Paper Mode 0 0~1 0:,Normal, 1: Tracing Paper mode (* Used as PreIPS C mode as well)
715-680 Default Value Color Balance Adjustment Level Y
Color Low density
4 0~8 Default Value Color Balance Adjustment Level Y Color Low density
715-681 Default Value Color Balance Adjustment Level Y
Color Medium density
4 0~8 Default Value Color Balance Adjustment Level Y Color Medium density
715-682 Default Value Color Balance Adjustment Level Y
Color High density
4 0~8 Default Value Color Balance Adjustment Level Y Color High density
715-683 Default Value Color Balance Adjustment Level M
Color Low density
4 0~8 Default Value Color Balance Adjustment Level M Color Low density
Table 3 IISS
Chain-Link Content Default Range Meaning
