Xerox WorkCentre 7132 Service Documentation

January 2007
6-106
WorkCentre 7132
Controller & Fax NVM List
Reversion 4.0
General procedures information
770-103 Gateway Address 0x000000
00~0xFFF
FFFFF
0.0.0.0 Read/Write 00000000~FFFFFFFF
770-110 DNS Auto Config. 0~0x10 DHCP Read/Write 0x10: Manual Setting, 0x02: DHCP
770-112 DNS Domain Name - NULL Read/Write DNS Domain Name (Normally, it is within 255 characters including the “.”
(dot) at the end which is not displayed)
770-120 WINS Auto Config. - DHCP Read/Write 0x10: Manual Setting, 0x02: DHCP
770-121 WINS Server Address 1 - 0.0.0.0 Read/Write 00000000~FFFFFFFF
770-123 WINS Server Address 2 0x000000
00~0xFFF
FFFFF
0.0.0.0 Read/Write 00000000~FFFFFFFF
770-130 Enable Setting 0~1 1: Enable Read/Write 0: Disable 1: Enable
770-131 Transport 0~3 2: UDP Read/Write 0: both OFF, 1: IPX, 2: UDP, 3: both ON
770-133 Community Name (For Set/Get Access) - NULL
(Replace to
“fxSystem
-
Mgr” on the
PDU)
Read/Write JISX0201 Character Code 12 Characters
770-140 Enable Setting 0~1 1: Enable Read/Write 0: Disable 1: Enable
770-150 Enable Setting 0~1 0; 1: Disable Read/Write 0: Disable 1: Enable
770-160 Enable Setting 0~1 0: Disable Read/Write 0: Disable 1: Enable
770-166 No. of concurrent requests received 1~10 5 Read/Write 1~10
770-190 Enable, Disable 0~1 1: Enable Read/Write 1: Enable, 0: Disable
770-191 Addressee of Mail Sender (Self-machine
mail address)
- NULL Read/Write Maximum 128 ASCII characters (Character type includes alphanumeric, [@][.
(period)][+][-][=][_ (underscore)][/][<][>]) username@domain.name format
770-202 SMTP Mail Server IP Address 0x000000
00~0xFFF
FFFFF
0.0.0.0 Read/Write 00000000~FFFFFFFF
770-222 Start Setup 0, 1 1 Read/Write 0: Stop, 1: Start
770-250 Adobe Communication Protocol 0~2 0: Standard Read/Write 0: Standard, 1: Binary, 2: TBCP
770-251 JCL Switch 0~1 0: ON Read/Write 0: OFF 1: ON
770-252 Print Mode 1~29 Auto Read/Write 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10:
TIFF, 2: PCL, 17: KS5843, 18: KSSM, 29: KS5895.
770-254 Enable Setting 0~1 1: Enable Read/Write 0: Disable 1: Enable
770-255 Auto Feed Time 0~255 6 (30sec) Read/Write 1-255 (5-1275 sec)
770-280 Enable Setting 0~1 1: Enable Read/Write 0: Disable 1: Enable
770-281 Print Mode 1~29 10: TIFF Read 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10:
TIFF, 2: PCL, 17: KS5843, 18: KSSM, 29: KS5895.
Refer to the FF Host I/F of each product for the setup range.
770-282 JCL Switch 0~1 1: ON Read 0: OFF, 1: ON
770-283 Filter 0~1 0: None Read 0: None, 1: TBCP
770-284 Spool Type 0~1 0: Non Spool Read 0: Non Spool (Ring Buffer), 1: Spool (RAM Disk)
Table 4 I/O Port Protocol
Chain-Link NVM Name
Setup
Range Initial Value Read/Write Description
