Xerox WorkCentre 7132 Service Documentation

January 2007
6-105
WorkCentre 7132
Controller & Fax NVM List
General procedures information
Reversion 4.0
770-065 Connection Timeout Time 2~3600
2~3600sec
(Setup
range:
2~65,535)
16sec Read/Write
770-068 Port Number - 515 Read/Write 515, 8000~9999
770-070 Address Limitation (Valid for lpd in Japan
market)
0~1 0: OFF Read/Write 0: OFF, 1: ON
770-071 Receive IP Address 1 - 0.0.0.0 Read/Write 00000000~FFFFFFFF
770-072 Receive IP Address 2 - 0.0.0.0 Read/Write 00000000~FFFFFFFF
770-073 Receive IP Address 3 - 0.0.0.0 Read/Write 00000000~FFFFFFFF
770-074 Receive IP Address 4 - 0.0.0.0 Read/Write 00000000~FFFFFFFF
770-075 Receive IP Address 5 - 0.0.0.0 Read/Write 00000000~FFFFFFFF
770-077 SMTP Port Number 1~65535 25 Read/Write 1~65535
770-080 Enable Setting 0~1 1: Enable Read/Write 0: Disable 1: Enable
770-081 Print Mode 1~29 1: Auto Read/Write 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10:
TIFF, 2: PCL, 17: KS5843, 18: KSSM, 29: KS5895.
Refer to the FF Host I/F of each product for the setup range.
770-082 JCL Switch is set as PJL Switch for AP 0~1 1: ON Read/Write 0: OFF, 1: ON
770-083 Filter 0~1 0: None Read/Write 0: None, 1: TBCP
770-084 Spool Type 1 0: Non Spool Read/Write 0: Non Spool, 1: Spool
770-085 Transport 2~6 6: both Read/Write 2: TCP/IP, 4: NetBeui, 6: both
770-090 Enable Setting 0~1 0: Disable Read/Write 0: Disable 1: Enable
770-091 Print Mode 1~29 1: Auto Read/Write 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10:
TIFF, 2: PCL, 17: KS5843, 18: KSSM, 29: KS5895.
Refer to the FF Host I/F of each product for the setup range.
770-092 JCL Switch 0~1 1: ON Read/Write 0: OFF, 1: ON
770-093 Filter 0~1 0: None Read/Write 0: None, 1: TBCP
770-094 Acl Authorization (Acl Authorization) 0~1 0: OFF
(none)
Read/Write 1: ON (local), 0: OFF (none)
770-095 Use DNS Name 0~1 1: ON Read/Write 1: ON, 0: OFF
770-097 Port no. (Value can be changed by user) 9999 80 Read/Write 0, 80, any one value between 8000~9999
770-098 Spool Type 1 0: Non Spool
is 1
Read/Write 0: Non Spool, 1: Spool
770-099 Time Out 0~65535 60 Read/Write 0~65535 [Sec]
770-100 IP Address Solution 1~0x10 2: DHCP Read/Write 0x10: Manual, 4: BOOTP, 2: DHCP, 1: RARP
770-101 IP Address 0x000000
00~0xFFF
FFFFF
0.0.0.0 Read/Write 00000000~FFFFFFFF
770-102 Subnet Mask 0x000000
00~0xFFF
FFFFF
0.0.0.0 Read/Write 00000000~FFFFFFFF
Table 4 I/O Port Protocol
Chain-Link NVM Name
Setup
Range Initial Value Read/Write Description
