Xerox WorkCentre 7132 Service Documentation

January 2007
6-104
WorkCentre 7132
Controller & Fax NVM List
Reversion 4.0
General procedures information
Chain 770-xxx I/O Port Protocol
Table 4 I/O Port Protocol
Chain-Link NVM Name
Setup
Range
Initial Value Read/Write Description
770-001 Enable Setting 0~1 1: Enable Read/Write 0: Disable 1: Enable
770-002 Print Mode 0~29 1: Auto Read/Write 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 9: 201H, 5: Post-
Script, 10: TIFF, 2: PCL, 17: KS5843, 18: KSSM, 29: KS5895.
Refer to the FF Host I/F of each product for the setup range.
770-003 JCL Switch 0~1 1: ON Read/Write 0: OFF, 1: ON
770-004 Adobe Communication Protocol 0~2 0: Standard Read/Write 0: Standard, 1: Binary, 2: TBCP
770-005 Auto Feed Time 1~255 6 (30sec) Read/Write 1-255 (5-1275 sec)
770-006 Input Prime 0~1 1: ON Read/Write 0: OFF, 1: ON
770-007 Bi-directional Mode 0~1 0: ON Read/Write 0: ON, 1: OFF
770-009 Applicable Communication Specification 0~1 0: IEEE
P1284
Read/Write 0: IEEE P1284, 1: Centronics
770-010 Operation Speed 1~0x7F 0x7F (127):
Auto
Read/Write 0x7F: Auto, 2: 100BASE-TX, 1: 10BASE-T
770-011 JBA 2004 Extensions 0, 1 0: Not sup-
ported
Read 0: Not supported, 1: Operate in expanded mode
770-012 Enable Setting 0, 1 1: Enable Read/Write 0: Disable, 1: Enable
770-020 Operation Speed - 4: Auto Read/Write Auto:4, 4MB/s: 1, 16MB/s: 2, 100MB/s: 3
770-021 Maximum Packet Size - 1500 Read/Write 1500, 2088, 4472, 8232
770-030 Operation Frame Type Setting 0~255 255: Auto Read/Write 255: Auto, 2: Ethernet II, 4: Ethernet SNAP, 3: Ethernet 802.2, 1: Ethernet
802.3, 6: Token SNAP, 5: Token 802.5
770-040 Enable Setting 0~1 0: Disable Read/Write 0: Disable 1: Enable
770-041 Print Mode - 5: PostScript Read/Write PostScript
770-042 JCL Switch is set as PJL Switch for AP 0~1 1: ON Read/Write 0: OFF, 1: ON
770-050 Enable Setting 0~1 0: Disable Read/Write 0: Disable 1: Enable
770-051 Print Mode 0~29 1: Auto Read/Write 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10:
TIFF, 2: PCL, 17: KS5843, 18: KSSM, 29: KS5895.
Refer to the FF Host I/F of each product for the setup range.
770-052 JCL Switch 0~1 1: Enable Read/Write 0: Disable, 1: Enable
770-053 Filter 0~1 0: None Read/Write 0: None, 1: TBCP
770-054 Transport 0~3 1: IPX/SPX Read/Write 1: IPX/SPX, 2: TCP/IP, 3: both
770-060 Enable Setting 0~1 1: Enable Read/Write 0: Disable 1: Enable
770-061 Print Mode 1~29 1: Auto Read/Write 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10:
TIFF, 2: PCL, 17: KS5843, 18: KSSM, 29: KS5895.
Refer to the FF Host I/F of each product for the setup range.
770-062 JCL Switch 0~1 1: ON Read/Write 0: OFF, 1: ON
770-063 Filter 0~1 0: None Read/Write 0: None, 1: TBCP
770-064 Spool Type 0~1 0: Non Spool Read/Write 0: Non Spool, 1: Spool
