Xerox WorkCentre 7132 Service Documentation

January 2007
6-108
WorkCentre 7132
Controller & Fax NVM List
Reversion 4.0
General procedures information
Chain 770-xxx 840-xxx Scan Service
770-342 IT Option MAC Address #1 0x0~0xFF 0x0 Read/Write Byte 1 of IT Option MAC Address
770-343 IT Option MAC Address #2 0x0~0xFF 0x0 Read/Write Byte 2 of IT Option MAC Address
770-344 IT Option MAC Address #3 0x0~0xFF 0x0 Read/Write Byte 3 of IT Option MAC Address
770-345 IT Option MAC Address #4 0x0~0xFF 0x0 Read/Write Byte 4 of IT Option MAC Address
770-346 IT Option MAC Address #5 0x0~0xFF 0x0 Read/Write Byte 5 of IT Option MAC Address
770-347 IT Option MAC Address #6 0x0~0xFF 0x0 Read/Write Byte 6 of IT Option MAC Address
770-400 Enable Setting 0, 1 0: Disable Read/Write 0: Disable, 1: Enable
770-401 Port No. (User modifiable value) 0~65535 80 Read/Write Port no.
770-402 Time-Out 0~65535 30 Read/Write Time-Out (Seconds)
Table 4 I/O Port Protocol
Chain-Link NVM Name
Setup
Range Initial Value Read/Write Description
Table 5 Scan Service
Chain-Link NVM Name
Setup
Range
Initial Value Read/Write Description
770-301 Directory Server (Primary) - FQDN - NULL Read/Write Below 64 bytes. Refer to RFC1034 for the available characters.
770-302 Directory Server (Primary) - IP Address - NULL Read/Write Below 4 bytes. Invalid if FQDN is specified. Invalid if retrieval by
DHCP is specified. 1.1.1.1~254.254.254.254
770-303 Directory Server (Primary) - LDAP Port No. 1~65535 389 Read/Write 1~65535
770-304 Directory Server (Secondary) - FQDN - NULL Read/Write Below 64 bytes. Refer to RFC1034 for the available characters.
770-305 Directory Server (Secondary) - IP Address - NULL Read/Write Below 4 bytes. Invalid if FQDN is specified. Invalid if retrieval by
DHCP is specified. 1.1.1.1~254.254.254.254
770-306 Directory Server (Secondary) - LDAP Port
No.
1~65535 389 Read/Write 1~65535
840-001 Scan Feature Setting 0~1 0: Enable Read/Write 0: Enable, 1: Disable
840-002 Scan Illegal Operation (Operation when
there was no specific timing when an error
occurs in storing)
0~1 0: Enable
Stored Doc
-
ument
Read/Write 0: Discard stored documents, 1: Enable stored documents
840-003 Maximum No. of Storage 1~999 999 sheets Read/Write 1~999 sheets
840-004 Brightness 3 Setting 0~200 192: -92
(Density)
Read/Write 0~200: -100~100
840-005 Brightness 2 Setting 0~200 161: -61
(Density)
Read/Write 0~200: -100~100
840-006 Brightness 1 Setting 0~200 131: -31
(Density)
Read/Write 0~200: -100~100
840-007 Brightness -1 Setting 0~200 99: 1 (Den-
sity)
Read/Write 0~200: -100~100
840-008 Brightness -2 Setting 0~200 98: 2 (Den-
sity)
Read/Write 0~200: -100~100
840-009 Brightness -3 Setting 0~200 97: 3 (Den-
sity)
Read/Write 0~200: -100~100
840-010 Brightest Setting 0~200 150:50 Read/Write 0~200: -100~100
