WorkCentre 7132
Controller & Fax NVM List
Reversion 4.0
General procedures information
825-018 Line Cutoff detection For Ch1 0~1 1: Detect disconnec-
tion
Read/Write 0: Do not detect disconnection, 1: Detect disconnection
825-019 Line Cutoff detection For Ch2 0~1 1: Detect disconnec-
tion
Read/Write 0: Do not detect disconnection, 1: Detect disconnection
825-020 Line Cutoff detection For Ch3 0~1 1: Detect disconnec-
tion
Read/Write 0: Do not detect disconnection, 1: Detect disconnection
825-021 Line Cutoff detection For Ch4 0~1 1: Detect disconnec-
tion
Read/Write 0: Do not detect disconnection, 1: Detect disconnection
825-022 Line Cutoff detection For Ch5 0~1 1: Detect disconnec-
tion
Read/Write 0: Do not detect disconnection, 1: Detect disconnection
825-024 To determine fallback redial from G4 to G3
when CAUSE #42 and #65 were received
in ISDN communication.
0~1 0 = Fallback Redial
OFF
Read/Write 0 = Fallback Redial OFF, 1 = Fallback Redial ON
825-025 Process to determine continuity in the
Transmitter when RTN was received. This
is meant for ZZF.
0~1 0: Continue Read/Write 0: Determine the fallback from the TCF check result and con-
tinue sending. 1: Stop transmission. (The document becomes
eligible for resend)
825-033 Timing of tone detection before dialing
(PBX). The time required to detect the
Tone before dialing. For PBX.
0~255 4 Read/Write 0 ~ 255 (Sec)
825-046 PB Send Level Ch0 0~15 6 Read/Write 0: 0dBm (0) ~-15: 15dBm step: -1dBm
825-047 PB Send Level Ch1 0~15 6 Read/Write 0: 0dBm (0) ~-15: 15dBm step: -1dBm
825-048 PB Send Level Ch2 0~15 6 Read/Write 0: 0dBm (0) ~-15: 15dBm step: -1dBm
825-049 PB Send Level Ch3 0~15 6 Read/Write 0: 0dBm (0) ~-15: 15dBm step: -1dBm
825-050 PB Send Level Ch4 0~15 6 Read/Write 0: 0dBm (0) ~-15: 15dBm step: -1dBm
825-051 PB Send Level Ch5 0~15 6 Read/Write 0: 0dBm (0) ~-15: 15dBm step: -1dBm
825-052 PB Send Level (high-pass - low-pass (dB))
For Ch0
0~15 0 Read/Write High-pass - Low-pass (dB) 0: 2.0, 1:
2.52:3.0A3:3.5A4:4.0A5:4.5A6:5.0A7:5.5A8:-2.0A9:-1.5A10:-
1.0A11:-0.5A12:0 13:0.5A14:1.0A15:1.5
825-053 PB Send Level (high-pass - low-pass (dB))
For Ch1
0~15 0 Read/Write High-pass - Low-pass (dB) 0: 2.0, 1:
2.52:3.0A3:3.5A4:4.0A5:4.5A6:5.0A7:5.5A8:-2.0A9:-1.5A10:-
1.0A11:-0.5A12:0 13:0.5A14:1.0A15:1.5
825-054 PB Send Level (high-pass - low-pass (dB))
For Ch2
0~15 0 Read/Write High-pass - Low-pass (dB) 0: 2.0, 1:
2.52:3.0A3:3.5A4:4.0A5:4.5A6:5.0A7:5.5A8:-2.0A9:-1.5A10:-
1.0A11:-0.5A12:0 13:0.5A14:1.0A15:1.5
825-055 PB Send Level (high-pass - low-pass (dB))
For Ch3
0~15 0 Read/Write High-pass - Low-pass (dB) 0: 2.0, 1:
2.52:3.0A3:3.5A4:4.0A5:4.5A6:5.0A7:5.5A8:-2.0A9:-1.5A10:-
1.0A11:-0.5A12:0 13:0.5A14:1.0A15:1.5
825-056 PB Send Level (high-pass - low-pass (dB))
For Ch4
0~15 0 Read/Write High-pass - Low-pass (dB) 0: 2.0, 1:
2.52:3.0A3:3.5A4:4.0A5:4.5A6:5.0A7:5.5A8:-2.0A9:-1.5A10:-
1.0A11:-0.5A12:0 13:0.5A14:1.0A15:1.5
825-057 PB Send Level (high-pass - low-pass (dB))
For Ch5
0~15 0 Read/Write High-pass - Low-pass (dB) 0: 2.0,1:
2.52:3.0A3:3.5A4:4.0A5:4.5A6:5.0A7:5.5A8:-2.0A9:-1.5A10:-
1.0A11:-0.5A12:0 13:0.5A14:1.0A15:1.5
Table 11 NVM 825 FAX Service
Chain-Link NVM Name
Setup
Range Initial Value Read/Write Description
