Xerox WorkCentre 7132

January 2007
6-151
WorkCentre 7132
Controller & Fax NVM List
General procedures information
Reversion 4.0
823-043 Set the service (for which contract is made)
in Ch1
- 0: Normal line Read/Write Assign the service in Bits and display the service (for which the
contract is made) in that disjunction.
MSB LSB
xxxx xxx1: Local ID Notification Service Line
xxxx xx1x: Modem Dial-In Service Line
823-044 Set the service (for which contract is made)
in Ch2
- 0: Normal line Read/Write Assign the service in Bits and display the service (for which the
contract is made) in that disjunction.
MSB LSB
xxxx xxx1: Local ID Notification Service Line
xxxx xx1x: Modem Dial-In Service Line
823-045 Set the service (for which contract is made)
in Ch3
- 0: Normal line Read/Write Assign the service in Bits and display the service (for which the
contract is made) in that disjunction.
MSB LSB
xxxx xxx1: Local ID Notification Service Line
xxxx xx1x: Modem Dial-In Service Line
823-046 Set the service (for which contract is made)
in Ch4
- 0: Normal line Read/Write Assign the service in Bits and display the service (for which the
contract is made) in that disjunction.
MSB LSB
xxxx xxx1: Local ID Notification Service Line
xxxx xx1x: Modem Dial-In Service Line
823-047 Set the service (for which contract is made)
in Ch5
- 0: Normal line Read/Write Assign the service in Bits and display the service (for which the
contract is made) in that disjunction.
MSB LSB
xxxx xxx1: Local ID Notification Service Line
xxxx xx1x: Modem Dial-In Service Line
823-049 G3 ISDN Transmission Capability Setting 0~1 0: 3.1K Audio Read/Write 0: 3.1K Audio, 1: Speech
823-050 Calling frequency for Fax use (Ring Detect) 0~9 0: 0 times Read/Write 0~9 (times)
823-051 Reception Paper Declaration Mode Selec-
tion (The Receiving Station performs the
Receive Ability (Size) with respect to the
Sending Station. With this, the user at
receiving side can limit or select the Send
document size from the Sender)
0~1 0: Tray Selection Read/Write 0: Tray Selection, 1: User Selection
823-052 Selection of Log Paper in User declaration
mode
- All papers available Read/Write 1st byte bit 1: A3SEF, bit 2: A4SEF, bit 5: B4SEF, 2nd byte bit 0:
LetterSEF, 3rd byte bit 2: A4LEF, bit 3: A5LEF, bit 6: B5LEF, bit
=0: No paper bit=1: Paper detected.
825-001 1300HZ Incoming Receive ON/OFF Set-
ting
0~1 1=ON (Receive) Read/Write 0: OFF (Reject), 1: ON (Receive)
825-002 Registers Power Cutoff/Reboot (including
emergency) in Activity Report.
0~1 0: Do not register Read/Write 0: Do not register, 1: Register
825-009 Pause Time. Pause Symbol Wait Time. 0~12 60 (3sec) Read/Write 0sec (0) ~ 12sec (240)
step=50msec
825-017 Line Cutoff Detection for Ch0 0~1 1: Detect disconnec-
tion
Read/Write 0: Do not detect disconnection, 1: Detect disconnection
Table 11 NVM 825 FAX Service
Chain-Link NVM Name
Setup
Range Initial Value Read/Write Description
