Xerox WorkCentre 7132

January 2007
6-150
WorkCentre 7132
Controller & Fax NVM List
Reversion 4.0
General procedures information
823-019 Receive Print/Page Composition (2up) 0~1 0: Page Composi-
tion OFF
Read/Write 0: Page Composition OFF, 1: Page Composition ON
823-020 Page Segmentation Threshold 0x00~0x7F 16mm (0x10) Read/Write 0mm (0) ~127mm (0x7F), step=1mm
823-021 Auto Reduction Mode (Auto Reduction
Receive: If the Receive Information has
exceeded the length of paper used for
recording but within the threshold limit, you
can use variable zoom to reduce the infor
-
mation to fit into a sheet of paper.)
0~1 1: Auto Reduction Read/Write 0: Print at 100%, 1: Auto Reduce
823-022 Batch Send. If Send reservation for the
same address is available after the last
page is sent, the Send transmission will
continue without disconnecting.
0~1 1: ON Read/Write 0: OFF, 1: ON
823-023 Sending from LOCAL I.D 0~1 1: ON Read/Write 0: Disable, 1: Enable
823-024 ISDN Local ID Send Setting for Ch0 0~1 0: Do not send Read/Write 0: Do not send, 1: Send
823-025 ISDN Local ID Send Setting for Ch1 0~1 0: Do not send Read/Write 0: Do not send, 1: Send
823-026 ISDN Local ID Send Setting for Ch2 0~1 0: Do not send Read/Write 0: Do not send, 1: Send
823-027 ISDN Local ID Send Setting for Ch3 0~1 0: Do not send Read/Write 0: Do not send, 1: Send
823-028 ISDN Local ID Send Setting for Ch4 0~1 0: Do not send Read/Write 0: Do not send, 1: Send
823-029 ISDN Local ID Send Setting for Ch5 0~1 0: Do not send Read/Write 0: Do not send, 1: Send
823-030 Dial Type For Ch0 0~2 0 Read/Write 0: PB (DTMF), 1: DP (10 PPS), 2: DP (20 PPS)
823-031 Dial Type For Ch1 0~2 0 Read/Write 0: PB (DTMF), 1: DP (10 PPS), 2: DP (20 PPS)
823-032 Dial Type For Ch2 0~2 0 Read/Write 0: PB (DTMF), 1: DP (10 PPS), 2: DP (20 PPS)
823-033 Dial Type For Ch3 0~2 0 Read/Write 0: PB (DTMF), 1: DP (10 PPS), 2: DP (20 PPS)
823-034 [NVM Name] Dial Type For Ch4 0~2 0 Read/Write 0 = PB (DTMF), 1 = DP (10 PPS), 2 = DP (20 PPS)
823-035 Dial Type For Ch5 0~2 0 Read/Write 0: PB (DTMF), 1: DP (10 PPS), 2: DP (20 PPS)
823-036 Line Type For Ch0 0~1 1 Read/Write 0: PSTN (Public Telephone Network), 1: PBX (Private Branch
Exchange)
823-037 Line Type For Ch1 0~1 0 Read/Write 0: PSTN (Public Telephone Network), 1: PBX (Private Branch
Exchange)
823-038 Line Type For Ch2 0~1 0 Read/Write 0: PSTN (Public Telephone Network), 1: PBX (Private Branch
Exchange)
823-039 Line Type For Ch3 0~1 0 Read/Write 0: PSTN (Public Telephone Network), 1: PBX (Private Branch
Exchange)
823-040 Line Type For Ch4 0~1 0 Read/Write 0: PSTN (Public Telephone Network), 1: PBX (Private Branch
Exchange)
823-041 Line Type For Ch5 0~1 0 Read/Write 0: PSTN (Public Telephone Network), 1: PBX (Private Branch
Exchange)
823-042 Set the service (for which contract is made)
in Ch0.
- 0: Normal line Read/Write Assign the service in Bits and display the service (for which the
contract is made) in that disjunction.
MSB LSB
xxxx xxx1: Local ID Notification Service Line
xxxx xx1x: Modem Dial-In Service Line
Table 11 NVM 825 FAX Service
Chain-Link NVM Name
Setup
Range Initial Value Read/Write Description
