Xerox WorkCentre 7132 Service Documentation

January 2007
6-178
WorkCentre 7132
Component Control
Reversion 4.0
General procedures information
Stacking Component Codes
NOTE: Some components cannot be energized at the same time as another component. If you
activate such a combination of components, the first component switched on will be automati
-
cally switched off.
1. When perform multiple component checking. input new Chain-Link number after one (or
several) component(s) is (are) in operating.
NOTE: Only latest Chain-Link number indicates.
2. When confirm the status of another component still in progress, select Enter Number then
input Chain-Link number of applicable component.
3. Select Stop key after confirming.
Stop operation of component indicated on screen.
NOTE: There are no Cyclic Component in below category:
• IIT Input Component.
• IIT Output Component.
• IOT Input Component.
Table 1 Input Component Control Codes IOT
Chain-Link Name
Connector
Level
Meaning Remarks
012-110 Registration Clutch ON H IOT Regi Clutch ON
012-111 IOT Exit Sensor H with paper
012-150 Compile Exit Sensor H with paper
012-151 Compile Tray No Paper Sensor H with paper
012-190 H-Transport Ent. Sensor H with paper
012-191 H-Transport Exit Sensor H with paper
012-220 Front Tamper Home Sensor H other than home position
012-221 Rear Tamper Home Sensor H other than home position
012-240 Stapler Move Home Sensor H other than home position
012-241 Stapler Move Position Sensor H other than home position
012-242 Low Staple Sensor H without pin
012-243 Self Priming Sensor H Not Ready
012-244 Staple Home Sensor H other than home position
012-250 Eject Clamp Home Sensor H other than home position
012-251 Set Clamp Home Sensor H other than home position
012-260 Upper Limit Sensor H upper limit position
012-262 Stacker No Paper Sensor H without finisher
012-267 Stacker Height Sensor H With Paper
012-268 Stacker Stock A Sensor H Cover Position
012-269 Stacker Stock B Sensor H Cover Position
012-280 Compiler Cover Safety Switch H Compiler Upper Chute Open
012-301 Top Cover Switch H Top Cover is closed
012-302 Finisher Front Cover Switch H Finisher Front Cover is closed
012-303 H-Transport Interlock Sensor H H-Transport is closed
042-200 Belt Home Position Sensor L Same as Name -
047-200 FACE UP TRAY DETECTED L Detected EXIT
047-201 OCT2 DETECTED L Detected EXIT
047-205 OCT1 HOME POSITION SENSOR L OCT1 is at its home position EXIT
047-206 OCT2 HOME POSITION SENSOR L OCT2 is at its home position EXIT
061-200 Polygon Motor Lock L PLYGON_MOT_LOCK signal is displayed.
061-201 ROS Motor Fan H ROS_FAN_FAIL signal is displayed.
