January 2007
6-179
WorkCentre 7132
Component Control
General procedures information
Reversion 4.0
071-100 #1 Pre-Feed Sensor L with paper
071-101 #1 No Paper Sensor L with paper
071-102 #1 Level Sensor H with paper
071-103 #1 Tray Paper Size Sensor H with paper
072-100 #2 Pre-Feed Sensor L with paper
072-101 #2 No Paper Sensor L with paper
072-102 #2 Level Sensor L with paper
072-103 #2 Feed Out Sensor H with paper
072-104 #2 Tray Paper Size Sensor H with paper
073-100 #3 Pre-Feed Sensor L with paper
073-101 #3 No Paper Sensor L with paper
073-102 #3 Level Sensor H with paper
073-103 #3 Feed Out Sensor H with paper
073-104 #3 Tray Paper Size Sensor H with paper
075-100 MSI No Paper Sensor H Same as Name
077-100 Regi Sensor L Same as Name
077-101 #1 Feed Out Sensor L Same as Name
077-102 #2 Exit Sensor L Same as Name
077-103 #2 OCT Home Position Sensor L Same as Name
077-104 Dup Wait Sensor L Same as Name
077-105 #1 Exit Sensor H Same as Name
077-106 Dup Regi Sensor - Same as Name
077-107 Dup Regi CL - Dup Regi Clutch Hotline
077-200 #2 Exit Unit Detect Line - Same as Name
077-201 Face Up Tray Detect Switch - Same as Name
077-300 Left Hand Interlock Switch - Same as Name
077-301 Left Hand Low Cover Switch - Same as Name
077-302 Left Hand High Cover Switch - Same as Name
077-303 Front Interlock Switch - Same as Name
077-305 Dup Cover Switch - Same as Name
077-306 TM Left Hand Interlock Switch - Same as Name
089-100 Registration SENSOR L with paper
089-101 Registration SENSOR (DM) H with paper Sensor level detected by DM DM
089-200 Registration CLUTCH (DM) L in ON state Signal detected by DM MODULE DM
089-201 Registration CLUTCH(EXIT) L in ON state Signal detected by EXIT MODULE EXIT
091-200 Waste Toner Bottle Sensor - Same as Name
091-201 Waste Toner Bottle Near Full Sensor - Same as Name
093-200 Rotary Home Position Sensor Same as Name
094-200 2nd BTR Retract Sensor - 2nd BTR Retract Sensor on/off is detected.
[I/O]2nd BTR Retract Sensor
Table 1 Input Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Remarks
To Next Page
