Xerox WorkCentre 7132

January 2007
6-184
WorkCentre 7132
Component Control
Reversion 4.0
General procedures information
077-020 TM Takeaway Clutch - Same as Name O X
077-021 TM Takeaway Motor (High) - Same as Name O X
077-022 TM Takeaway Motor (Low) - Same as Name O X
091-001 BCR DC BIAS - Same as Name X X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
091-002 BCR AC BIAS - Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
091-003 BCR DC/AC BIAS - Same as Name X X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
091-004 Drum Motor (Normal Speed) - Same as Name X X
091-005 DRUM MOTOR(Half Speed) - Same as Name X X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
091-006 Erase Lamp - Same as Name X X
092-001 ADC Specular - ADC specular reflection LED is
turned on/off.
O
X Not Available
092-002 ADC Diffuse - ADC regular reflection LED is turned
on/off.
O
X Not Available
092-003 ADC Shutter Open - ADC Shutter is opened.
[I/O]TMA Shutter Open
After executing this Component Con-
trol, MOB ADC Shutter needs to be
closed. Otherwise, the sensor inside
the shutter may be contaminated
(MOB ADC shutter will be automati
-
cally closed when printing)
O
X Not Available
092-004 ADC Shutter Close - ADC Shutter is closed.
O
X Not Available
092-005 Toner Dispense - Toner Dispense Clutch is turned on
(turned off in 2 seconds)
O
X Not Available
093-001 Deve Bias-DC L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-002 Deve Bias-AC L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks
