January 2007
6-183
WorkCentre 7132
Component Control
General procedures information
Reversion 4.0
073-001 Tray 3 Feed/Lift Up Motor (CW) - Turn Lift Up Motor on for two sec-
onds when Tray 3 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 3 Level Sensor is
''H''(lifted up).
O X
073-002 Tray 3 Feed/Lift Up Motor (CCW) - Turn Lift Up Motor on for two sec-
onds when Tray 3 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 3 Level Sensor is
''H''(lifted up).
O X
075-001 MSI Feed Solenoid - MSI Feed Solenoid is turned on for
200mseconds.
X X DM
077-001 Take Away Clutch - Take Away Clutch is turned on.
[I/O]TA Clutch (doubled as MSI TA
clutch)
[Component] By combining with Main
Drive Motor [042-001], Take Away
Clutch can be driven by #1 Take
Away Roll and MSI Take Away Roll.
O X Stack Code:042-001-Main Drive Motor
077-002 Regi Clutch - Registration Clutch is turned on.?
[I/O]TA Clutch (doubled as MSI TA
clutch)
[Component] By combining with Main
Drive Motor[042-001], Regi Clutch
can be driven by Regi Roll.
O X Stack Code:042-001-Main Drive Motor
077-003 Exit Gate Solenoid - Exit Gate is turned off/on.
Off: Printed sheets are ejected to Exit
1
On: Printed sheets are ejected to
Exit2. [I/O] Exit Gate Solenoid
O X
077-004 Face Up Gate Solenoid - Face Up Gate is turned off/on.
Off: Printed sheets are ejected to
Exit2.
On: Printed sheets are ejected to
Face Up Tray.
[I/O] Face Up Gate Solenoid
O X
077-005 #2 Exit Motor Fan - Air is sent to Exit 2 Drive Motor.
[I/O] Exit MOTOR FAN
O X
077-006 DUP Motor - Duplex Unit Feed Roll is driven.
[I/O] DUP MOTOR
O X
077-007 Exit 2 Drive Motor (Full Speed CW) - Same as Name O X
077-008 Exit 2 Drive Motor (Full Speed CCW) - Same as Name O X
077-009 Exit 2 Drive Motor (Half Speed CW) - Same as Name O X
077-011 OCT 2 Motor (CW) - Same as Name O X
077-012 OCT 2 Motor (CCW) - Same as Name O X
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks
