WorkCentre 7132
Component Control
Reversion 4.0
General procedures information
047-005 OFFSET MOTOR1 REVERSE ROTA-
TION
- Same as Name X X EXIT
047-022 EXIT DRIVE MOTOR FORWARD (Eject
Paper out)
- Same as Name X X Not Available
047-023 EXIT DRIVE MOTOR REVERSE (send
paper into Dup)
- Same as Name X X Not Available
047-024 Exit Gate Solenoid H Switch Gate to Exit2/FUT X X Not Available
047-025 FACE UP GATE SOLENOID L Switch FUT Gate to Face Up Tray X X EXIT
047-026 EXIT 2 FAN - Exit 2 FAN rotating X X Not Available
061-001 ROS Motor ON - Send a pulse to
PLYGON_MOT_CLK (this pulse is
generated when ROS main task is
initiated).
X X
061-002 ROS Fan ON - ROS Fan is activated X X
071-001 Tray 1 Feed/Lift Up Motor (CW2) - Turn Lift Up Motor on for two sec-
onds when Tray 1 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 1 Level Sensor is
''H''(lifted up).
O X
071-002 Tray 1 Feed/Lift Up Motor (CCW2) - Turn Lift Up Motor on for two sec-
onds when Tray 1 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 1 Level Sensor is
''H''(lifted up).
O X
071-003 Tray 1 Feed/Lift Up Motor (CW12) - Turn Lift Up Motor on for two sec-
onds when Tray 1 Level Sensor is
''L'' (lifted down). Lifter Motor will not
rotate when Tray 1 Level Sensor is
''H''(lifted up).
O X
071-004 Tray 1 Feed/Lift Up Motor (CCW12) - Turn Lift Up Motor on for two sec-
onds when Tray 1 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 1 Level Sensor is
''H''(lifted up).
O X
072-001 Tray 2 Feed/Lift Up Motor (CW) - Turn Lift Up Motor on for two sec-
onds when Tray 2 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 2 Level Sensor is
''H''(lifted up).
O X
072-002 Tray 2 Feed/Lift Up Motor (CCW) - Turn Lift Up Motor on for two sec-
onds when Tray 2 Level Sensor is
''L''(lifted down). Lifter Motor will not
rotate when Tray 2 Level Sensor is
''H''(lifted up).
O X
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks
