Xerox WorkCentre 7132

January 2007
6-181
WorkCentre 7132
Component Control
General procedures information
Reversion 4.0
012-081 Eject Motor FORWARD ON/OFF - Same as Name X X
012-082 Eject Motor REVERSE ON/OFF - Same as Name X X
012-083 Eject Clamp Low DOWN - Same as Name X X
012-084 Eject Clamp Middle DOWN - Same as Name X X
012-085 Eject Clamp UP - Same as Name X X
012-086 Set Clamp Paddle Solenoid ON L Same as Name X X
042-001 Main Motor ON (Normal Speed) L Main motor rotation at normal pro-
cess speed.
[I/O] Main Motor
[I/O] Main Motor Gain1
[I/O] Main Motor Gain2
[I/O] Main Motor Clock
(normal process speed is determined
depending on combination on Main
Motor Gain 1, Main Motor Gain 2,
and Main Motor Clock).
- X
042-002 Main Motor ON (Half Speed) L Main motor rotation speed at half
process speed.
[I/O] Main Motor
[I/O] Main Motor Gain1
[I/O] Main Motor Gain2
[I/O] Main Motor Clock
(half process speed is determined
depending on combination o Main
Motor Gain 1, Main Motor Gain 2,
and Main Motor Clock).
- X
042-003 Auger Motor L Auger motor rotation
[I/O] Auger Motor
[I/O] Auger Motor CLK
- X
042-004 Developer Motor L Developer motor rotation
[I/O] Deve Motor
[I/O] Deve Motor CLK
- X
042-005 Fuser Fan L Fuser fan rotation
Fuser fan rotates at high speed per
start command.
Fuser fan rotates at low speed per
stop command
- X
042-006 Rear Fan L Rear fan rotation - X
047-001 OFFSET MOTOR1 FORWARD ROTA-
TION
- Same as Name X X EXIT
047-003 OFFSET MOTOR2 FORWARD ROTA-
TION
- Same as Name X X EXIT
047-004 OFFSET MOTOR2 REVERSE ROTA-
TION
- Same as Name X X EXIT
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks
