093-014 Rotary Check (Home-Mex) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-015 Rotary Check (Home-Cex) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-016 Rotary Check (Kex-Home) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-017 Rotary Check (Yex-Home) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-018 Rotary Check (Mex-Home) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-019 Rotary Check (Cex-Home) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-020 Rotary Check (Home-Kcr) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-021 Rotary Check (Home-Ycr) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-022 Rotary Check (Home-Mcr) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-023 Rotary Check (Home-Ccr) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-024 Rotary Check (Kcr-Home) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks
