093-025 Rotary Check (Ycr-Home) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-026 Rotary Check (Mcr-Home) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
093-027 Rotary Check (Ccr-Home) L Same as Name O X The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
094-001 1st BTR HVPS - 1st BTR HVPS is turned on/off.
<Operating Conditions>
1) Drum motor is turned on.
2) Erase lamp is turned on.
3) BCR AC is turned on/ BCR DC is
turned on.
4) 1st BTR HVPS is turned on (out-
put value can be adjusted by NVM
(nxfr_1stBtrOut): default value is 200
(20uA))
O O The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
094-002 2st BTR HVPS - 2nd BTR HVPS is turned on/off.
<Operating Conditions>
1) Drum motor is turned on.
2) 2nd BTR contact completed.
3) 2nd BTR HVPS is turned on (out-
put value can be adjusted by NVM
(nxfr_2ndBtrOut): default value is
100 (1000V))
O O The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
094-003 DTS HVPS - DTS HVPS is turned on/off (output
value can be adjusted by NVM
(nxfr_DtsOut): default value is 30
(3000V)).
O O
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks
