WorkCentre 7132
Component Control
Reversion 4.0
General procedures information
094-004 2st BTR Contact - 2nd BTR contact motion.
2nd BTR contact motion stops when
2nd BTR Retract Sensor detects that
2nd BTR is in the contact position.
1) I/O]2nd BTR Retract Clutch is
turned on.
2) [I/O]2nd BTR Retract Clutch is
turned off within a period of time
specified by the timer
(nxfr_2ndCntStpTime) after 2nd BTR
Retract Sensor is turned on.
[Component] Auger Mot needs to be
activated in advance.
O O The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
094-005 2st BTR Retract - 2nd BTR retract motion.
2nd BTR retract motion stops when
2nd BTR Retract Sensor detects that
2nd BTR is in retract position.
1) [I/O]2nd BTR Retract Clutch is
turned on.
2) [I/O]2nd BTR Retract Clutch is
turned off within a period of time
specified by the timer
(nxfr_2ndRetStpTime) after 2nd BTR
Retract Sensor is turned off.
[Component] Auger Mot needs to be
activated in advance.
O O The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
094-006 IBT CLN Contact - IBT cleaner contact motion.
IBT cleaner retract motion stops
when IBT Cleaner Retract Sensor
detects that IBT cleaner is in contact
position.
1) [I/O]IBT CLN Retract Clutch is
turned on.
2) [I/O]IBT CLN Retract Clutch is
turned off within a period of time
specified by the timer
(nxfr_ClnCntStpTime) after IBT
Cleaner Retract Sensor is turned on.
[Component] Auger Mot needs to be
activated in advance.
O O The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks
