094-007 IBT CLN Retract - IBT cleaner contact motion.
IBT cleaner retract motion stops
when IBT Cleaner Retract Sensor
detects that IBT cleaner is in contact
position.
1) [I/O]IBT CLN Retract Clutch is
turned on.
2) [I/O]IBT CLN Retract Clutch is
turned off within a period of time
specified by the timer
(nxfr_ClnCntStpTime) after IBT
Cleaner Retract Sensor is turned on.
[Component] Auger Mot needs to be
activated in advance.
O O The BCR AC, BCR DC, DEVE DC and BTR
output simultaneously. * CF=53-45(CL=751-
560) to 1 (single output) enables indepen
-
dent outputs.
094-008 IBT CLN Auger Clutch - BT CLN Auger Clutch is turned on/
off.
O O
094-009 2nd BTR Retract Clutch - 2nd BTR Retract Clutch is turned on/
off.
[I/O]2nd BTR Retract Clutch
O O
094-010 IBT CLN Retract Clutch - BTR CLN Retract Clutch is turned
on/off.
[I/O]BTR CLN Retract Clutch
Table 3 Input Component Control Codes IIT
Chain-Link Name Connector Level Meaning Remarks
005-102 Document Sensor H No paper detected by Document Sensor
005-110 Regi Sensor (Belt DADF/CVT) L Paper detected by Regi Sensor
005-205 DADF Feed Out Sensor H Paper detected by Feed Out Sensor
005-206 DADF Pre-Reg.Sensor H Paper detected by Pre-Reg. Sensor
005-211 DADF Invert Sensor H Paper detected by Inverter Sensor
005-212 DADF Feeder Cover Interlock Switch - Feeder Cover open
005-213 DADF Platen Interlock Switch H Platen Interlock open
005-215 DADF #1 Tray APS Sensor L Light is not blocked by the actuator
005-216 DADF #2 Tray APS Sensor L Light is not blocked by the actuator
005-217 DADF #3 Tray APS Sensor L Light is not blocked by the actuator
005-218 DADF #1 APS Sensor L paper detected by APS No.1 Sensor
005-219 DADF #2 APS Sensor L paper detected by APS No.1 Sensor
005-220 DADF #3 APS Sensor L paper detected by APS No.1 Sensor
005-221 DADF Tray Size SNR No.1 L paper detected by Tray Size SNR No.1
005-222 DADF Tray Size SNR No.2 L paper detected by Tray Size SNR No.2
005-224 Scan Start H Scan Start Signal ON
005-225 Nudger Position Snr H The Nudger Roll is at UP position.
062-201 Sheet Abort L Document Regist
Table 2 Output Component Control Codes IOT
Chain-Link Name
Connector
Level Meaning Timer Off Cycle Operation Remarks
