Xerox WorkCentre 7132

January 2007
6-190
WorkCentre 7132
Component Control
Reversion 4.0
General procedures information
062-212 IIT Regi Sensor L De-actuation of Regi Sensor
062-240 ADF Exist H DADF is not installed
062-251 APS Sensor1 APS SNR1:L APS ON: H Document detected
062-253 APS Sensor3 APS SNR3:L APS ON: H Document detected
062-272 Scan Start L Scan available
062-280 CCD Fan Fail H Same as Name
062-281 IPS Fan Fail H Same as Name
062-280 Lamp Fan Fail H Same as Name
062-300 Platen I/L Switch L Platen closed
062-301 Angle Sensor L Platen opened
Table 4 Output Component Control Codes IIT
Chain-Link Name Connector Level Meaning Timer Off
Multiple Output
Prohibited Items
Remarks
005-001 DADF Feed Motor(Speed1) - ON for 50sec -> Auto OFF O 005-002~005-014
005-002 DADF Feed Motor(Speed2) - ON for 50sec -> Auto OFF O 005-001
005-003~005-014
005-003 DADF Feed Motor(Speed3) - ON for 50sec -> Auto OFF O 005-001~005-002
005-004~005-014
005-004 DADF Feed Motor(Speed4) - ON for 50sec -> Auto OFF O 005-001~005-003
005-005~005-014
005-005 DADF Feed Motor(Speed5) - ON for 50sec -> Auto OFF O 005-001~005-004
005-006~005-014
005-006 DADF Feed Motor(Speed6) - ON for 50sec -> Auto OFF O 005-001~005-005
005-007~005-014
005-007 DADF Feed Motor(Speed7) - ON for 50sec -> Auto OFF O 005-001~005-006
005-008~005-014
005-008 DADF Feed Motor(Speed8) - ON for 50sec -> Auto OFF O 005-001~005-
007005-009~005-
014
005-009 DADF Feed Motor(Speed9) - ON for 50sec -> Auto OFF O 005-001~005-008
005-010~005-014
005-010 DADF Feed Motor(Speed10) - ON for 50sec -> Auto OFF O 005-001~005-009
005-013~005-014
005-013 DADF Feed Motor(Speed11) - ON for 50sec -> Auto OFF O 005-001~005-010
005-014
005-014 DADF Feed Motor(Reverse) - ON for 50sec -> Auto OFF O 005-001~005-013
005-026 DADF Reg.Motor(Speed1) - ON for 50sec -> Auto OFF O 005-027~005-036
005-027 DADF Reg.Motor(Speed2) - ON for 50sec -> Auto OFF O 005-026
005-028~005-036
005-028 DADF Reg.Motor(Speed3) - ON for 50sec -> Auto OFF O 005-026~005-027
005-029~005-036
Table 3 Input Component Control Codes IIT
Chain-Link Name Connector Level Meaning Remarks
