005-029 DADF Reg.Motor(Speed4) - ON for 50sec -> Auto OFF O 005-026~005-028
005-030~005-036
005-030 DADF Reg.Motor(Speed5) - ON for 50sec -> Auto OFF O 005-026~005-029
005-031~005-036
005-031 DADF Reg.Motor(Speed6) - ON for 50sec -> Auto OFF O 005-026~005-030
005-032~005-036
005-032 DADF Reg.Motor(Speed7) - ON for 50sec -> Auto OFF O 005-026~005-031
005-033~005-036
005-033 DADF Reg.Motor(Speed8) - ON for 50sec -> Auto OFF O 005-026~005-032
005-034~005-036
005-034 DADF Reg.Motor(Speed9) - ON for 50sec -> Auto OFF O 005-026~005-033
005-035~005-036
005-036 DADF Reg.Motor(Reverse) - ON for 50sec -> Auto OFF O 005-026~005-036
005-072 Nip Release Solenoid L 3sec on O -
005-083 Doc Ready L Turn ON the Doc Ready
signal.
X -
005-084 Doc Set LED L Belt: Turn ON the DOC
SET LED
X(Belt)
O(DADF)
-
005-088 Image Area H ON for 5sec O -
005-090 Nudger initialize - Performs Nudger Roll ini-
tialization.
O -
062-002 IIT Exposure Lamp L Turn the Lamp ON for
180sec -> Auto OFF
O - Turn it OFF when Stop command is
received before Auto OFF.
062-004 IPS Cooling Fan (Low speed) L Same as name O -
062-005 IIT Scan Motor (Scan) Each has 4 phases.
H/L Switching
Move it 50mm from cur-
rent position in Scan
direction -> Auto OFF
O 062-006 Stop command is not accepted before
Auto OFF.
062-006 IIT Scan Motor (Return) Each has 4 phases.
H/L Switching
Move it 50mm from cur-
rent position in Return
direction -> Auto OFF
O 062-005 Stop command is not accepted before
Auto OFF.
062-014 IPS Cooling Fan (High speed) H Same as name O -
062-015 Lamp Cooling Fan H Same as name O -
062-017 CCD Cooling Fan H Same as name O -
062-086 IIT Image Area (Differential) H IMAGE-AREA Signal Out-
put
X -
062-091 Exchange To ADF L Turn ON the document
exchange command sig
-
nal to the DADF
X -
Table 4 Output Component Control Codes IIT
Chain-Link Name Connector Level Meaning Timer Off
Multiple Output
Prohibited Items Remarks
