Xerox WorkCentre 7132

January 2007
6-192
WorkCentre 7132
Component Control
Reversion 4.0
General procedures information
Table 5 Input Component Control Codes A-Finisher
Chain-Link Name
Connector
Level Meaning Remarks
012-110 Regi Clutch ON Low IOT Regi Clutch status Clutch ON
012-111 IOT Exit SNR High IOT Exit SNR status (Hot
Line)
Paper exists.
012-140 Ent SNR High Paper Detection by Ent
SNR
Paper exists.
012-150 Compile Exit SNR High Paper Detection by Com-
piler Exit SNR
Paper exists.
012-220 Front Tamper Home SNR High Detection of Front
Tamper Position
Not Home
(receiving light)
012-221 Rear Tamper Home SNR High Detection of Rear Tamper
Position
Not Home
(receiving light)
012-242 Low Staple SNR High Detection of staples in
Stapler and of Staple Car
-
tridge
No staples
012-243 Self Priming SNR High Detection of the status
where Stapler Staple is
ready
Not Ready
012-244 Staple Home SNR High Detection of Staple Head
Position
Not Home
012-251 Set Clamp Home SNR High Detection of Set Clamp
Position
Not Home
(receiving light)
012-252 Eject Home SNR High Detection of Eject Belt
Position
Not Home
(receiving light)
012-267 Stack Height Sensor Low Detection of paper on
Stacker Tray
Detects Stacker height.
012-278 Stack Sensor1 High Detection of Stacker Tray
Position
Shield exists.
012-279 Stack Sensor2 High Detection of Stacker Tray
Position
Shield exists.
012-300 Top Cover Interlock High Detection of Open/Closed
Top Cover
Open
012-302 Finisher Front Door SW High Detection of Open/Closed
Front Door
Open
Table 6 Output Component Control Codes A-Finisher
Chain-Link Name Connector Meaning Time Off
Multiple Output
Prohibited Items
012-013 Sub Paddle Solenoid ON/OFF L: ON H: OFF Sub Paddle rotation 660ms 012-014
