Xerox WorkCentre 7132 Service Documentation

January 2007
6-195
WorkCentre 7132
Component Control
General procedures information
Reversion 4.0
012-095 Transport Motor Low ON/OFF Pulse: ON
H: OFF
Transport Mot rotates for-
ward at low speed (equal
to full IOT speed).
- 012-014
012-096
012-097
012-096 Transport Motor Hi ON/OFF Pulse: ON
H: OFF
Transport Mot rotates for-
ward at high speed (trans-
port speed in Finisher).
- 012-014
012-095
012-097
012-097 Transport Motor Half Speed ON/OFF Pulse: ON
H: OFF
Transport Mot rotates for-
ward at half speed (equal
to half IOT speed).
- 012-014
012-095
012-096
Table 6 Output Component Control Codes A-Finisher
Chain-Link Name Connector Meaning Time Off
Multiple Output
Prohibited Items
