Xerox WorkCentre 7132 Service Documentation

January 2007
7-4
WorkCentre 7132
Plug/Jack Locations
Reversion 4.0
Wiring-data
P/J203 Figure 11 Sensor Bar, WasteContainer, IOT Left Side
P/J205 Figure 7 7 Duplex Unit, MSI
P/J207 Figure 5 4 Exit2
P/J208 Figure 5 5 Exit2
P/J209 Figure 5 7 Exit2
P/J210 Figure 5 3 Exit2
P/J211 Figure 13 IOT Rear Location
P/J212 Figure 7 6 Duplex Unit, MSI
P/J213 Figure 13 IOT Rear Location
P/J214 Figure 13 IOT Rear Location
P/J215 Figure 13 IOT Rear Location
P/J217 Figure 13 IOT Rear Location
P/J218 Figure 13 IOT Rear Location
P/J219 Figure 4 ROS Unit
P/J220 Figure 5 1 Exit 2
P/J220A Figure 17 1 Tray2/3 Feeder(2TM)
P/J220A Figure 19 1 Tray2/3 Feeder(TTM)
P/J220B Figure 17 1 Tray2/3 Feeder(2TM)
P/J220B Figure 19 1 Tray2/3 Feeder(TTM)
P/J221 Figure 13 IOT Rear Location
P/J222 Figure 13 IOT Rear Location
P/J226 Figure 13 IOT Rear Location
P304 Figure 10 ESS
J330 Figure 10 ESS
J331 Figure 10 ESS
J333 Figure 10 ESS
J334 Figure 10 ESS
P/J136 Figure 11 Sensor Bar, WasteContainer, IOT Left Side
P/J137 Figure 11 Sensor Bar, WasteContainer, IOT Left Side
J338 Figure 10 ESS
J340 Figure 10 ESS
J343 Figure 10 ESS
J344 Figure 10 ESS
P351 Figure 10 ESS
P380 Figure 10 ESS
P353 Figure 12 2 Fax Box Assembly
P354 Figure 12 3 Fax Box Assembly
P356 Figure 12 4 Fax Box Assembly
P/J380 Figure 12 1 Fax Box Assembly
J356 Figure 12 4 Fax Box Assembly
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
J359 Figure 12 5 Fax Box Assembly
J360 Figure 12 6 Fax Box Assembly
P/J380 Figure 12 FAX Box
P382 Figure 10 ESS
P/J387 Figure 10 ESS
P/J388 Figure 10 ESS
P/J389 Figure 14 MCU PWB
P/J390 Figure 14 MCU PWB
P/J400 Figure 14 MCU PWB
P/J401 Figure 14 MCU PWB
P/J402 Figure 14 MCU PWB
P/J405 Figure 14 MCU PWB
P/J406 Figure 14 MCU PWB
P/J407 Figure 14 MCU PWB
P/J408 Figure 14 MCU PWB
P/J409 Figure 14 MCU PWB
P/J410 Figure 14 MCU PWB
P/J411 Figure 14 MCU PWB
P/J412 Figure 14 MCU PWB
P/J413 Figure 14 MCU PWB
P/J415 Figure 14 MCU PWB
P/J416 Figure 14 MCU PWB
J416 Figure 25 8 Finisher Rear Location
P/J417 Figure 14 MCU PWB
P/J420 Figure 14 MCU PWB
P/J421 Figure 14 MCU PWB
P/J422 Figure 14 MCU PWB
P/J423 Figure 14 MCU PWB
P/J424 Figure 14 MCU PWB
P/J425 Figure 14 MCU PWB
P/J426 Figure 14 MCU PWB
P/J450 Figure 14 MCU PWB
P/J451 Figure 14 MCU PWB
P/J452 Figure 14 MCU PWB
P/J453 Figure 14 MCU PWB
P/J500 Figure 3 HVPS, IOT Front View
P/J502 Figure 25 11 Finisher Rear Location
P/J505 Figure 25 12 Finisher Rear Location
P/J510 Figure 16 Power Unit
P/J511 Figure 16 Power Unit
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
