Xerox WorkCentre 7132 Service Documentation

January 2007
7-5
WorkCentre 7132
Plug/Jack Locations
Wiring-data
Reversion 4.0
P/J512 Figure 16 Power Unit
P/J513 Figure 16 Power Unit
P/J514 Figure 16 Power Unit
P/J540 Figure 7 3 Duplex Unit, MSI
P/J541 Figure 7 4 Duplex Unit, MSI
P/J541 Figure 18 2 2TM Rear Location
P/J541 Figure 20 1 TTM Rear Location
P/J542 Figure 7 5 Duplex Unit, MSI
P/J548 Figure 18 1 2TM Rear Location
P/J548 Figure 20 11 TTM Rear Location
P/J549 Figure 18 7 2TM Rear Location
P/J549 Figure 18 9 2TM Rear Location
P/J549 Figure 20 10 TTM Rear Location
P/J549 Figure 20 12 TTM Rear Location
P/J552 Figure 18 8 2TM Rear Location
P/J552 Figure 20 9 TTM Rear Location
P/J554 Figure 18 3 2TM Rear Location
P/J554 Figure 20 2 TTM Rear Location
P/J223 Figure 13 5 IOT Rear Location
P/J601 Figure 11 Sensor Bar, WasteContainer, IOT Left Side
P/J611 Figure 9 6 L/H Lower, Tray1 Feeder
P/J603 Figure 3 HVPS, IOT Front View
P/J604 Figure 3 HVPS, IOT Front View
P/J605 Figure 8 Regi Sensor, Regi Clutch
P606 Figure 5 10 Exit 2
P/J612 Figure 9 5 L/H Lower, Tray1 Feeder
P/J609 Figure 7 8 Duplex Unit, MSI
P/J610 Figure 7 11 Duplex Unit
P/J611 Figure 9 L/H Lower, Tray1 Feeder
P/J612 Figure 9 L/H Lower, Tray1 Feeder
P/J613 Figure 9 L/H Lower, Tray1 Feeder
P/J614 Figure 6 Fuser
P/J616 Figure 2 IIT
P/J617 Figure 3 HVPS, IOT Front View
P/J619 Figure 16 LVPS
P/J618 Figure 4 ROS Unit
P/J621 Figure 6 Fuser
P/J661A Figure 17 8 Tray2/3 Feeder(2TM)
P/J661A Figure 20 4 TTM Rear Location
P/J661B Figure 17 9 Tray2/3 Feeder(2TM)
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
P/J661B Figure 19 7 TTM Rear Location
P/J700 Figure 2 11 IIT
P/J702 Figure 2 6 IIT
P/J703 Figure 2 5 IIT
P/J710 Figure 2 14 IIT
P/J719 Figure 2 4 IIT
P/J720 Figure 2 9 IIT
P/J721 Figure 2 1 IIT
P/J722 Figure 2 13 IIT
P/J723 Figure 2 8 IIT
P/J725 Figure 2 2 IIT
P/J727 Figure 2 15 IIT
P/J728 Figure 2 7 IIT
J750 Figure 2 3 IIT
P750 Figure 22 15 DADF 2 of 2
P/J751 Figure 22 16 DADF 2 of 2
P/J752 Figure 22 14 DADF 2 of 2
P/J753 Figure 22 13 DADF 2 of 2
P/J754 Figure 22 12 DADF 2 of 2
P/J755 Figure 22 11 DADF 2 of 2
P/J756 Figure 22 5 DADF 2 of 2
P/J757 Figure 22 4 DADF 2 of 2
P/J758 Figure 22 3 DADF 2 of 2
P/J759 Figure 22 2 DADF 2 of 2
P/J760 Figure 22 1 DADF 2 of 2
P/J761 Figure 22 17 DADF 2 of 2
P/J764 Figure 22 9 DADF 2 of 2
P/J765 Figure 22 10 DADF 2 of 2
P/J766 Figure 21 3 DADF 1 of 2
P/J767 Figure 21 18 DADF 1 of 2
P/J769 Figure 22 8 DADF 2 of 2
P/J770 Figure 22 7 DADF 2 of 2
P/J771 Figure 21 14 DADF 1 of 2
P/J772 Figure 21 15 DADF 1 of 2
P/J774 Figure 21 13 DADF 1 of 2
P/J775 Figure 21 16 DADF 1 of 2
P/J776 Figure 21 17 DADF 1 of 2
P/J777 Figure 21 7 DADF 1 of 2
P/J778 Figure 21 6 DADF 1 of 2
P/J779 Figure 21 5 DADF 1 of 2
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
