Xerox WorkCentre 7132 Service Documentation

January 2007
7-6
WorkCentre 7132
Plug/Jack Locations
Reversion 4.0
Wiring-data
P/J780 Figure 21 12 DADF 1 of 2
P/J781 Figure 21 11 DADF 1 of 2
P/J782 Figure 21 10 DADF 1 of 2
P/J785 Figure 22 18 DADF 2 of 2
P/J786 Figure 22 6 DADF 2 of 2
P/J787 Figure 21 9 DADF 1 of 2
P/J788 Figure 21 8 DADF 1 of 2
P/J791 Figure 21 4 DADF 1 of 2
P/J820 Figure 17 4 Tray2/3 Feeder(2TM)
P/J820 Figure 19 5 Tray2/3 Feeder(TTM)
P/J821 Figure 17 7 Tray2/3 Feeder(2TM)
P/J821 Figure 19 6 Tray2/3 Feeder(TTM)
P/J822 Figure 18 5 2TM Rear Location
P/J822 Figure 20 7 TTM Rear Location
P/J824 Figure 17 5 Tray2/3 Feeder(2TM)
P/J824 Figure 19 4 Tray2/3 Feeder(TTM)
P/J825 Figure 17 6 Tray2/3 Feeder(2TM)
P/J825 Figure 20 3 TTM Rear Location
P/J826 Figure 18 6 2TM Rear Location
P/J826 Figure 20 8 TTM Rear Location
P/J841 Figure 18 4 2TM Rear Location
P/J841 Figure 20 5 TTM Rear Location
P/J842 Figure 17 10 Tray2/3 Feeder(2TM)
P/J842 Figure 20 6 TTM Rear Location
P/J869 Figure 25 13 Finisher Rear Location
P/J871 Figure 24 16 Finisher Front Location
P/J7261 Figure 2 10 IIT
P/J7262 Figure 2 12 IIT
P/J8379 Figure 23 2 H-Transport Assembly
P/J8380 Figure 23 1 H-Transport Assembly
P/J8381 Figure 23 3 H-Transport Assembly
P/J8382 Figure 23 4 H-Transport Assembly
P/J8390 Figure 26 4 Finisher PWB
P/J8800 Figure 25 7 Finisher Rear Location
P/J8801 Figure 25 6 Finisher Rear Location
P/J8802 Figure 25 4 Finisher Rear Location
P/J8803 Figure 25 3 Finisher Rear Location
P/J8805 Figure 24 1 Finisher Front Location
P/J8806 Figure 24 4 Finisher Front Location
P/J8807 Figure 24 5 Finisher Front Location
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
P/J8808 Figure 24 6 Finisher Front Location
P/J8809 Figure 24 17 Finisher Front Location
P/J8810 Figure 24 7 Finisher Front Location
P/J8811 Figure 24 11 Finisher Front Location
P/J8812 Figure 24 12 Finisher Front Location
P/J8813 Figure 24 14 Finisher Front Location
P/J8814 Figure 25 2 Finisher Rear Location
P/J8815 Figure 25 1 Finisher Rear Location
P/J8817 Figure 24 10 Finisher Front Location
P/J8818 Figure 24 8 Finisher Front Location
P/J8819 Figure 24 9 Finisher Front Location
P/J8820 Figure 24 15 Finisher Front Location
P/J8822 Figure 25 5 Finisher Rear Location
P/J8823 Figure 24 3 Finisher Front Location
P/J8824 Figure 24 2 Finisher Front Location
P/J8825 Figure 24 13 Finisher Front Location
P/J8827 Figure 25 9 Finisher Rear Location
P/J8843 Figure 26 7 Finisher PWB
P/J8844 Figure 26 6 Finisher PWB
P/J8846 Figure 26 3 Finisher PWB
P/J8847 Figure 26 5 Finisher PWB
P/J8848 Figure 26 1 Finisher PWB
P/J8849 Figure 26 2 Finisher PWB
P/J8850 Figure 26 10 Finisher PWB
P/J8851 Figure 26 8 Finisher PWB
P/J8852 Figure 26 9 Finisher PWB
CN1 Figure 1 5 Control Panel
CN2 Figure 1 9 Control Panel
CN3 Figure 1 4 Control Panel
CN4 Figure 1 6 Control Panel
CN5 Figure 1 3 Control Panel
CON CN3 Figure 1 11 Control Panel
CP CN1 Figure 1 7 Control Panel
F1 Figure 21 2 DADF 1 of 2
F2 Figure 21 1 DADF 1 of 2
FS812 Figure 17 11 Tray2/3 Feeder(2TM)
FS812 Figure 19 8 Tray2/3 Feeder(TTM)
FS813 Figure 17 11 Tray2/3 Feeder(2TM)
FS813 Figure 19 8 Tray2/3 Feeder(TTM)
INV CN1 Figure 1 10 Control Panel
Table 1 Plug/Jack List
Connector
Number
Figure
Number
Item
Number Figure Title
