January 2007
4-12
WorkCentre 7132
REP 1.1.2
Reversion 4.0
Repairs/Adjustments
Figure 5 Preparing to remove the Drum Drive Assembly
10. Remove the Drum Drive Assembly.
1
Remove the
screws (5)
