Xerox WorkCentre 7132 Service Documentation

January 2007
4-39
WorkCentre 7132
REP 4.2.5
Repairs/Adjustments
Reversion 4.0
Figure 5 Removing the inner bracket
10. Release the tension of the Belt. (Figure 6)
Figure 6 Releasing the Belt tension
11. Remove the follower lever. (Figure 7)
2
Remove the bracket
1
Remove the screws (3)
Place the handle on the tension shaft
and rotate the handle clockwise then
remove the handle
