Analog Devices SHARC ADSP-21368 User Manual

SDRAM Controller
3-56 ADSP-21368 SHARC Processor Hardware Reference
Table 3-24. 16-Bit Row and Column Address Mapping
(1K Words)
Pin Column Address Row Address Bank Address Pins of SDRAM
A[18] IA[22] BA[1]
A[17] IA[21] BA[0]
A[13]
A[12] A[12]
A[11] IA[20] A[11]
SDA10 IA[19] A[10]
A[9] IA[8] IA[18] A[9]
A[8] IA[7] IA[17] A[8]
A[7] IA[6] IA[16] A[7]
A[6] IA[5] IA[15] A[6]
A[5] IA[4] IA[14] A[5]
A[4] IA[3] IA[13] A[4]
A[3] IA[2] IA[12] A[3]
A[2] IA[1] IA[11] A[2]
A[1] IA[0] IA[10] A[1]
A[0] 1/0 IA[9] A[0]
