ADSP-21368 SHARC Processor Hardware Reference 5-79

Serial Ports

Reserved

IISP4A 0x840 8 RXSP4A or TXSP4A

IMSP4A 0x841 8 RXSP4A or TXSP4A

CSP4A 0x842 8 RXSP4A or TXSP4A

CPSP4A 0x843 8 RXSP4A or TXSP4A

IISP4B 0x844 9 RXSP4B or TXSP4B

IMSP4B 0x845 9 RXSP4B or TXSP4B

CSP4B 0x846 9 RXSP4B or TXSP4B

CPSP4B 0x847 9 RXSP4B or TXSP4B

IISP5A 0x848 10 RXSP5A or TXSP5A

IMSP5A 0x849 10 RXSP5A or TXSP5A

CSP5A 0x84A 10 RXSP5A or TXSP5A

CPSP5A 0x84B 10 RXSP5A or TXSP5A

IISP5B 0x84C 11 RXSP5B or TXSP5B

IMSP5B 0x84D 11 RXSP5B or TXSP5B

CSP5B 0x84E 11 RXSP5B or TXSP5B

CPSP5B 0x84F 11 RXSP5B or TXSP5B

IISP6A 0x4840 12 RXSP6A or TXSP6A

IMSP6A 0x4841 12 RXSP6A or TXSP6A

CSP6A 0x4842 12 RXSP6A or TXSP6A

CPSP6A 0x4843 12 RXSP6A or TXSP6A

IISP6B 0x4844 13 RXSP6B or TXSP6B

IMSP6B 0x4845 13 RXSP6B or TXSP6B

CSP6B 0x4846 13 RXSP6B or TXSP6B

Table 5-13. SPORT DMA Parameter Registers Addresses (Cont’d)
