Input Data Port Registers
A-76 ADSP-21368 SHARC Processor Hardware Reference
4 IDP_P05_PDAPMASK Parallel Data Acquisition Port Mask.
0 = Input data from DAI_05/DATA0 is masked
1 = Input data from DAI_05/DATA0 is unmasked
5 IDP_P06_PDAPMASK Parallel Data Acquisition Port Mask.
0 = Input data from DAI_06/DATA1 is masked
1 = Input data from DAI_06/DATA1 is unmasked
6 IDP_P07_PDAPMASK Parallel Data Acquisition Port Mask.
0 = Input data from DAI_07/DATA2 is masked
1 = Input data from DAI_07/DATA2 is unmasked
7 IDP_P08_PDAPMASK Parallel Data Acquisition Port Mask.
0 = Input data from DAI_08/DATA3 is masked
1 = Input data from DAI_08/DATA3 is unmasked
8 IDP_P09_PDAPMASK Parallel Data Acquisition Port Mask.
0 = Input data from DAI_09/DATA4 is masked
1 = Input data from DAI_09/DATA4 is unmasked
9 IDP_P10_PDAPMASK Parallel Data Acquisition Port Mask.
0 = Input data from DAI_10/DATA5 is masked
1 = Input data from DAI_10/DATA5 is unmasked
10 IDP_P11_PDAPMASK Parallel Data Acquisition Port Mask.
0 = Input data from DAI_11/DATA6 is masked
1 = Input data from DAI_11/DATA6 is unmasked
11 IDP_P12_PDAPMASK Parallel Data Acquisition Port Mask.
0 = Input data from DAI_12/DATA7 is masked
1 = Input data from DAI_12/DATA7 is unmasked
12 IDP_P13_PDAPMASK Parallel Data Acquisition Port Mask.
0 = Input data from DAI_13/ADDR0 is masked
1 = Input data from DAI_13/ADDR0 is unmasked
13 IDP_P14_PDAPMASK Parallel Data Acquisition Port Mask.
0 = Input data from DAI_14/ADDR1 is masked
1 = Input data from DAI_14/ADDR1 is unmasked
14 IDP_P15_PDAPMASK Parallel Data Acquisition Port Mask.
0 = Input data from DAI_15/ADDR2 is masked
1 = Input data from DAI_15/ADDR2 is unmasked
Table A-24. IDP_PP_CTL Register Bit Descriptions (Cont’d)
Bit Name Description
