Interrupt Registers
B-10 ADSP-21368 SHARC Processor Hardware Reference
9 P18I (SPIB) Programmable Interrupt 18 (SPI B Interrupt). Indicates if
an SPIB interrupt is latched and pending (if set, = 1), or no
SPIBI interrupt is pending (if cleared, = 0).
10 P6IMSK
(SP0IMSK)
Programmable Interrupt Mask 6 (SPORT0 Interrupt
Mask). Unmasks the SP0I interrupt (if set, = 1), or masks the
SP0I interrupt (if cleared, = 0).
11 P7IMSK
(SP2IMSK)
Programmable Interrupt Mask 7 (SPORT2 Interrupt
Mask). Unmasks the SP2I interrupt (if set, = 1), or masks the
SP2I interrupt (if cleared, = 0).
12 P8IMSK
(SP4IMSK)
Programmable Interrupt Mask 8 (SPORT4 Interrupt
Mask). Unmasks the SP4I interrupt (if set, = 1), or masks the
SP4I interrupt (if cleared, = 0).
13 P9IMSK
(EPDMA0MSK)
Programmable Interrupt Mask 9 (External Port DMA
Channel 0 Interrupt Mask). Unmasks the EPDMA0 inter-
rupt (if set, = 1), or masks the EPDMA0 interrupt (if cleared,
= 0).
14 P10IMSK
(GPTMR1IMSK)
Programmable Interrupt Mask 9 (General-Purpose IOP
Timer 1 Interrupt Mask). Unmasks the GPTMR1I interrupt
(if set, = 1), or masks the GPTMR1I interrupt
(if cleared, = 0).
15 P11IMSK Programmable Interrupt Mask 11 (SPORT7 Interrupt
Mask). Unmasks the SP7I interrupt (if set, = 1), or masks the
SP7I interrupt (if cleared, = 0).
16 P12IMSK
(DAI2IMSK)
Programmable Interrupt Mask 12 (DAI2 Interrupt Mask).
Unmasks the DAI2I (if set, = 1), or masks DAI2I
(if cleared, = 0).
17 P13IMSK
(EPDMA1IMSK)
Programmable Interrupt Mask 12 (External Port DMA
Channel 1 Interrupt Mask). Unmasks the EPDMA1I inter-
rupt (if set, = 1), or masks EPDMA1I interrupt (if set, = 0).
18 P17IMSK
(GPTMR2IMSK)
Programmable Interrupt Mask 17 (General-Purpose IOP
Timer 2 Interrupt Mask.) Unmasks the GPTMR2I interrupt
(if set, = 1), or masks the GPTMR2I interrupt
(if cleared, = 0).
Table B-4. LIRPTL Register Bit Descriptions (Cont’d)
Bit Name Description
