R01UH0823EJ0100 Rev.1.00 Page 1019 of 1823

Jul 31, 2019

RX23W Group 33. Serial Communications Interface (SCIg, SCIh)

Table 33.27 Serial Transfer Formats (Asynchronous Mode)

S: Start bit

STOP: Stop bit

P: Parity bit

MPB: Multi-processor bit

SCMR

Setting SMR Setting Serial Transfer Format and Frame Length

CHR1 CHR PE MP STOP

12345678910111213

00000 S 9-bit data STOP

00001 S 9-bit data STOPSTOP

00100 S 9-bit data PSTOP

00101 S 9-bit data PSTOPSTOP

10000 S 8-bit data STOP

10001 S 8-bit data STOPSTOP

10100 S 8-bit data PSTOP

10101 S 8-bit data PSTOPSTOP

11000 S 7-bit data STOP

11001 S 7-bit data STOPSTOP

11100 S 7-bit data PSTOP

11101 S 7-bit data PSTOPSTOP

0 0 — 1 0 S 9-bit data MPB STOP

0 0 — 1 1 S 9-bit data MPB STOP STOP

1 0 — 1 0 S 8-bit data MPB STOP

1 0 — 1 1 S 8-bit data MPB STOP STOP

1 1 — 1 0 S 7-bit data MPB STOP

11—11

S 7-bit data MPB STOP STOP
