Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 111 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
0008 838Fh RSPI0 RSPI Control Register 2 SPCR2 8 8 2 or 3 PCLKB 2 ICLK section 38.
0008 8390h RSPI0 RSPI Command Register 0 SPCMD0 16 16 2 or 3 PCLKB 2 ICLK section 38.
0008 8392h RSPI0 RSPI Command Register 1 SPCMD1 16 16 2 or 3 PCLKB 2 ICLK section 38.
0008 8394h RSPI0 RSPI Command Register 2 SPCMD2 16 16 2 or 3 PCLKB 2 ICLK section 38.
0008 8396h RSPI0 RSPI Command Register 3 SPCMD3 16 16 2 or 3 PCLKB 2 ICLK section 38.
0008 8398h RSPI0 RSPI Command Register 4 SPCMD4 16 16 2 or 3 PCLKB 2 ICLK section 38.
0008 839Ah RSPI0 RSPI Command Register 5 SPCMD5 16 16 2 or 3 PCLKB 2 ICLK section 38.
0008 839Ch RSPI0 RSPI Command Register 6 SPCMD6 16 16 2 or 3 PCLKB 2 ICLK section 38.
0008 839Eh RSPI0 RSPI Command Register 7 SPCMD7 16 16 2 or 3 PCLKB 2 ICLK section 38.
0008 8410h IRDA IrDA Control Register IRCR 8 8 2 or 3 PCLKB 2 ICLK section 34.
0008 8900h POE Input Level Control/Status Register 1 ICSR1 16 8, 16 2 or 3 PCLKB 2 ICLK section 24.
0008 8902h POE Output Level Control/Status Register 1 OCSR1 16 8, 16 2 or 3 PCLKB 2 ICLK section 24.
0008 8908h POE Input Level Control/Status Register 2 ICSR2 16 8, 16 2 or 3 PCLKB 2 ICLK section 24.
0008 890Ah POE Software Port Output Enable Register SPOER 8 8 2 or 3 PCLKB 2 ICLK section 24.
0008 890Bh POE Port Output Enable Control Register 1 POECR1 8 8 2 or 3 PCLKB 2 ICLK section 24.
0008 890Ch POE Port Output Enable Control Register 2 POECR2 8 8 2 or 3 PCLKB 2 ICLK section 24.
0008 890Eh POE Input Level Control/Status Register 3 ICSR3 16 8, 16 2 or 3 PCLKB 2 ICLK section 24.
0008 9000h S12AD A/D Control Register ADCSR 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9004h S12AD A/D Channel Select Register A0 ADANSA0 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9006h S12AD A/D Channel Select Register A1 ADANSA1 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9008h S12AD A/D-Converted Value Addition/Average Function Select
Register 0
ADADS0 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 900Ah S12AD A/D-Converted Value Addition/Average Function Select
Register 1
ADADS1 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 900Ch S12AD A/D-Converted Value Addition/Average Count Select
Register
ADADC 8 8 2 or 3 PCLKB 2 ICLK section 44.
0008 900Eh S12AD A/D Control Extended Register ADCER 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9010h S12AD A/D Conversion Start Trigger Select Register ADSTRGR 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9012h S12AD A/D Conversion Extended Input Control Register ADEXICR 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9014h S12AD A/D Channel Select Register B0 ADANSB0 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9016h S12AD A/D Channel Select Register B1 ADANSB1 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9018h S12AD A/D Data Duplication Register ADDBLDR 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 901Ah S12AD A/D Temperature Sensor Data Register ADTSDR 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 901Ch S12AD A/D Internal Reference Voltage Data Register ADOCDR 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 901Eh S12AD A/D Self-Diagnosis Data Register ADRD 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9020h S12AD A/D Data Register 0 ADDR0 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9022h S12AD A/D Data Register 1 ADDR1 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9024h S12AD A/D Data Register 2 ADDR2 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9026h S12AD A/D Data Register 3 ADDR3 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9028h S12AD A/D Data Register 4 ADDR4 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 902Ah S12AD A/D Data Register 5 ADDR5 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 902Ch S12AD A/D Data Register 6 ADDR6 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 902Eh S12AD A/D Data Register 7 ADDR7 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9040h S12AD A/D Data Register 16 ADDR16 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9042h S12AD A/D Data Register 17 ADDR17 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9044h S12AD A/D Data Register 18 ADDR18 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9046h S12AD A/D Data Register 19 ADDR19 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9048h S12AD A/D Data Register 20 ADDR20 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 9056h S12AD A/D Data Register 27 ADDR27 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 907Ah S12AD A/D Disconnection Detection Control Register ADDISCR 8 8 2 or 3 PCLKB 2 ICLK section 44.
0008 907Dh S12AD A/D Event Link Control Register ADELCCR 8 8 2 or 3 P
CLKB 2 ICLK section 44.
000
8 9080h S12AD A/D Group Scan Priority Control Register ADGSPCR 16 16 2 or 3 PCLKB 2 ICLK section 44.
0008 908Ah S12AD A/D High-Potential/Low-Potential Reference Voltage
Control Register
ADHVREFCNT 8 8 2 or 3 PCLKB 2 ICLK section 44.
Table 5.1 List of I/O Registers (Address Order) (7/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK

Renesas RX Series Specifications

General

Core	RXv1, RXv2, RXv3
Flash Memory	Up to 8 MB
RAM	Up to 1 MB
Operating Voltage	1.62V to 5.5V
Operating Temperature	-40°C to +85°C or +105°C
Package	BGA, LQFP
ADC Resolution	12-bit
DAC Resolution	12-bit
Communication Interfaces	SCI, SPI, I2C, USB, Ethernet, CAN
Architecture	32-bit
Security Features	Memory Protection Unit (MPU)
