Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 110 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
0008 8210h TMR2 Timer Control Register TCR 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8211h TMR3 Timer Control Register TCR 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8212h TMR2 Timer Control/Status Register TCSR 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8213h TMR3 Timer Control/Status Register TCSR 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8214h TMR2 Time Constant Register A TCORA 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8214h TMR23 Time Constant Register A TCORA 16 16 2 or 3 PCLKB 2 ICLK section 26.
0008 8215h TMR3 Time Constant Register A TCORA 8 8*
1
2 or 3 PCLKB 2 ICLK section 26.
0008 8216h TMR2 Time Constant Register B TCORB 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8216h TMR23 Time Constant Register B TCORB 16 16 2 or 3 PCLKB 2 ICLK section 26.
0008 8217h TMR3 Time Constant Register B TCORB 8 8*
1
2 or 3 PCLKB 2 ICLK section 26.
0008 8218h TMR2 Timer Counter TCNT 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8218h TMR23 Timer Counter TCNT 16 16 2 or 3 PCLKB 2 ICLK section 26.
0008 8219h TMR3 Timer Counter TCNT 8 8*
1
2 or 3 PCLKB 2 ICLK section 26.
0008 821Ah TMR2 Timer Counter Control Register TCCR 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 821Ah TMR23 Timer Counter Control Register TCCR 16 16 2 or 3 PCLKB 2 ICLK section 26.
0008 821Bh TMR3 Timer Counter Control Register TCCR 8 8*
1
2 or 3 PCLKB 2 ICLK section 26.
0008 821Ch TMR2 Timer Counter Start Register TCSTR 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8280h CRC CRC Control Register CRCCR 8 8 2 or 3 PCLKB 2 ICLK section 39.
0008 8281h CRC CRC Data Input Register CRCDIR 8 8 2 or 3 PCLKB 2 ICLK section 39.
0008 8282h CRC CRC Data Output Register CRCDOR 16 16 2 or 3 PCLKB 2 ICLK section 39.
0008 8300h RIIC0 I
2
C-bus Control Register 1 ICCR1 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8301h RIIC0 I
2
C-bus Control Register 2 ICCR2 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8302h RIIC0 I
2
C-bus Mode Register 1 ICMR1 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8303h RIIC0 I
2
C-bus Mode Register 2 ICMR2 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8304h RIIC0 I
2
C-bus Mode Register 3 ICMR3 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8305h RIIC0 I
2
C-bus Function Enable Register ICFER 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8306h RIIC0 I
2
C-bus Status Enable Register ICSER 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8307h RIIC0 I
2
C-bus Interrupt Enable Register ICIER 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8308h RIIC0 I
2
C-bus Status Register 1 ICSR1 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8309h RIIC0 I
2
C-bus Status Register 2 ICSR2 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 830Ah RIIC0 Slave Address Register L0 SARL0 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 830Bh RIIC0 Slave Address Register U0 SARU0 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 830Ch RIIC0 Slave Address Register L1 SARL1 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 830Dh RIIC0 Slave Address Register U1 SARU1 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 830Eh RIIC0 Slave Address Register L2 SARL2 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 830Fh RIIC0 Slave Address Register U2 SARU2 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8310h RIIC0 I
2
C-bus Bit Rate Low-Level Register ICBRL 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8311h RIIC0 I
2
C-bus Bit Rate High-Level Register ICBRH 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8312h RIIC0 I
2
C-bus Transmit Data Register ICDRT 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8313h RIIC0 I
2
C-bus Receive Data Register ICDRR 8 8 2 or 3 PCLKB 2 ICLK section 35.
0008 8380h RSPI0 RSPI Control Register SPCR 8 8 2 or 3 PCLKB 2 ICLK section 38.
0008 8381h RSPI0 RSPI Slave Select Polarity Register SSLP 8 8 2 or 3 PCLKB 2 ICLK section 38.
0008 8382h RSPI0 RSPI Pin Control Register SPPCR 8 8 2 or 3 PCLKB 2 ICLK section 38.
0008 8383h RSPI0 RSPI Status Register SPSR 8 8 2 or 3 PCLKB 2 ICLK section 38.
0008 8384h RSPI0 RSPI Data Register SPDR 32 16, 32 2 or 3 PCLKB 2 ICLK section 38.
0008 8388h RSPI0 RSPI Sequence Control Register SPSCR 8 8 2 or 3 PCLKB 2 ICLK section 38.
0008 8389h RSPI0 RSPI Sequence Status Register SPSSR 8 8 2 or 3 PCLKB 2 ICLK section 38.
0008 838Ah RSPI0 RSPI Bit Rate Register SPBR 8 8 2 or 3 PCLKB 2 ICLK section 38.
0008 838Bh RSPI0 RSPI Data Control Register SPDCR 8 8 2 or 3 PCLKB 2 ICLK section 38.
0008 838Ch RSPI0 RSPI Clock Delay Register SPCKD 8 8 2 or 3 PCLKB 2 ICLK section 38.
0008 838Dh RSPI0 RSPI Slave Select Negation Delay Register SSLND 8 8 2 or 3 PCLKB 2 ICLK section 38.
0008 838Eh RSPI0 RSPI Next-Access Delay Register SPND 8 8 2 or 3 PCLKB 2 ICLK section 38.
Table 5.1 List of I/O Registers (Address Order) (6/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK

Renesas RX Series Specifications

General

Core	RXv1, RXv2, RXv3
Flash Memory	Up to 8 MB
RAM	Up to 1 MB
Operating Voltage	1.62V to 5.5V
Operating Temperature	-40°C to +85°C or +105°C
Package	BGA, LQFP
ADC Resolution	12-bit
DAC Resolution	12-bit
Communication Interfaces	SCI, SPI, I2C, USB, Ethernet, CAN
Architecture	32-bit
Security Features	Memory Protection Unit (MPU)
