Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 109 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
0008 8130h TPU2 Timer Control Register TCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8131h TPU2 Timer Mode Register TMDR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8132h TPU2 Timer I/O Control Register TIOR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8134h TPU2 Timer Interrupt Enable Register TIER 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8135h TPU2 Timer Status Register TSR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8136h TPU2 Timer Counter TCNT 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 8138h TPU2 Timer General Register A TGRA 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 813Ah TPU2 Timer General Register B TGRB 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 8140h TPU3 Timer Control Register TCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8141h TPU3 Timer Mode Register TMDR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8142h TPU3 Timer I/O Control Register H TIORH 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8143h TPU3 Timer I/O Control Register L TIORL 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8144h TPU3 Timer Interrupt Enable Register TIER 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8145h TPU3 Timer Status Register TSR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8146h TPU3 Timer Counter TCNT 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 8148h TPU3 Timer General Register A TGRA 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 814Ah TPU3 Timer General Register B TGRB 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 814Ch TPU3 Timer General Register C TGRC 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 814Eh TPU3 Timer General Register D TGRD 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 8150h TPU4 Timer Control Register TCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8151h TPU4 Timer Mode Register TMDR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8152h TPU4 Timer I/O Control Register TIOR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8154h TPU4 Timer Interrupt Enable Register TIER 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8155h TPU4 Timer Status Register TSR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8156h TPU4 Timer Counter TCNT 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 8158h TPU4 Timer General Register A TGRA 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 815Ah TPU4 Timer General Register B TGRB 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 8160h TPU5 Timer Control Register TCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8161h TPU5 Timer Mode Register TMDR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8162h TPU5 Timer I/O Control Register TIOR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8164h TPU5 Timer Interrupt Enable Register TIER 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8165h TPU5 Timer Status Register TSR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8166h TPU5 Timer Counter TCNT 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 8168h TPU5 Timer General Register A TGRA 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 816Ah TPU5 Timer General Register B TGRB 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 8200h TMR0 Timer Control Register TCR 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8201h TMR1 Timer Control Register TCR 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8202h TMR0 Timer Control/Status Register TCSR 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8203h TMR1 Timer Control/Status Register TCSR 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8204h TMR0 Time Constant Register A TCORA 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8204h TMR01 Time Constant Register A TCORA 16 16 2 or 3 PCLKB 2 ICLK section 26.
0008 8205h TMR1 Time Constant Register A TCORA 8 8*
1
2 or 3 PCLKB 2 ICLK section 26.
0008 8206h TMR0 Time Constant Register B TCORB 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8206h TMR01 Time Constant Register B TCORB 16 16 2 or 3 PCLKB 2 ICLK section 26.
0008 8207h TMR1 Time Constant Register B TCORB 8 8*
1
2 or 3 PCLKB 2 ICLK section 26.
0008 8208h TMR0 Timer Counter TCNT 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 8208h TMR01 Timer Counter TCNT 16 16 2 or 3 PCLKB 2 ICLK section 26.
0008 8209h TMR1 Timer Counter TCNT 8 8*
1
2 or 3 PCLKB 2 ICLK section 26.
0008 820Ah TMR0 Timer Counter Control Register TCCR 8 8 2 or 3 PCLKB 2 ICLK section 26.
0008 820Ah TMR01 Timer Counter Control Register TCCR 16 16 2 or 3 PCLKB 2 ICLK section 26.
0008 820Bh TMR1 Timer Counter Control Register TCCR 8 8*
1
2 or 3 PCLKB 2 ICLK section 26.
0008 820Ch TMR0 Timer Counter Start Register TCSTR 8 8 2 or 3 PCLKB 2 ICLK section 26.
Table 5.1 List of I/O Registers (Address Order) (5/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK
