Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 108 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
0008 8006h CMT0 Compare Match Constant Register CMCOR 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 8008h CMT1 Compare Match Timer Control Register CMCR 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 800Ah CMT1 Compare Match Counter CMCNT 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 800Ch CMT1 Compare Match Constant Register CMCOR 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 8010h CMT Compare Match Timer Start Register 1 CMSTR1 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 8012h CMT2 Compare Match Timer Control Register CMCR 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 8014h CMT2 Compare Match Counter CMCNT 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 8016h CMT2 Compare Match Constant Register CMCOR 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 8018h CMT3 Compare Match Timer Control Register CMCR 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 801Ah CMT3 Compare Match Counter CMCNT 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 801Ch CMT3 Compare Match Constant Register CMCOR 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 8020h WDT WDT Refresh Register WDTRR 8 8 2 or 3 PCLKB 2 ICLK section 30.
0008 8022h WDT WDT Control Register WDTCR 16 16 2 or 3 PCLKB 2 ICLK section 30.
0008 8024h WDT WDT Status Register WDTSR 16 16 2 or 3 PCLKB 2 ICLK section 30.
0008 8026h WDT WDT Reset Control Register WDTRCR 8 8 2 or 3 PCLKB 2 ICLK section 30.
0008 8030h IWDT IWDT Refresh Register IWDTRR 8 8 2 or 3 PCLKB 2 ICLK section 31.
0008 8032h IWDT IWDT Control Register IWDTCR 16 16 2 or 3 PCLKB 2 ICLK section 31.
0008 8034h IWDT IWDT Status Register IWDTSR 16 16 2 or 3 PCLKB 2 ICLK section 31.
0008 8036h IWDT IWDT Reset Control Register IWDTRCR 8 8 2 or 3 PCLKB 2 ICLK section 31.
0008 8038h IWDT IWDT Count Stop Control Register IWDTCSTPR 8 8 2 or 3 PCLKB 2 ICLK section 31.
0008 8040h DA D/A Data Register 0 DADR0 16 16 2 or 3 PCLKB 2 ICLK section 45.
0008 8042h DA D/A Data Register 1 DADR1 16 16 2 or 3 PCLKB 2 ICLK section 45.
0008 8044h DA D/A Control Register DACR 8 8 2 or 3 PCLKB 2 ICLK section 45.
0008 8045h DA Data Register Format Select Register DADPR 8 8 2 or 3 PCLKB 2 ICLK section 45.
0008 8046h DA D/A A/D Synchronous Start Control Register DAADSCR 8 8 2 or 3 PCLKB 2 ICLK section 45.
0008 8047h DA D/A VREF Control Register DAVREFCR 8 8 2 or 3 PCLKB 2 ICLK section 45.
0008 8100h TPU Timer Start Register TSTR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8101h TPU Timer Synchronous Register TSYR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8108h TPU0 Noise Filter Control Register NFCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8109h TPU1 Noise Filter Control Register NFCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 810Ah TPU2 Noise Filter Control Register NFCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 810Bh TPU3 Noise Filter Control Register NFCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 810Ch TPU4 Noise Filter Control Register NFCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 810Dh TPU5 Noise Filter Control Register NFCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8110h TPU0 Timer Control Register TCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8111h TPU0 Timer Mode Register TMDR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8112h TPU0 Timer I/O Control Register H TIORH 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8114h TPU0 Timer Interrupt Enable Register TIER 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8115h TPU0 Timer Status Register TSR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8116h TPU0 Timer Counter TCNT 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 8118h TPU0 Timer General Register A TGRA 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 811Ah TPU0 Timer General Register B TGRB 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 811Ch TPU0 Timer General Register C TGRC 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 811Eh TPU0 Timer General Register D TGRD 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 8120h TPU1 Timer Control Register TCR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8121h TPU1 Timer Mode Register TMDR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8122h TPU1 Timer I/O Control Register TIOR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8124h TPU1 Timer Interrupt Enable Register TIER 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8125h TPU1 Timer Status Register TSR 8 8 2 or 3 PCLKB 2 ICLK section 25.
0008 8126h TPU1 Timer Counter TCNT 16 16 2 or 3 PCLKB 2 ICLK section 25.
0008 8128h TPU1 Timer General Register A TGRA 16 16 2 or 3 PCLKB 2 ICL
K section 25.
000
8 812Ah TPU1 Timer General Register B TGRB 16 16 2 or 3 PCLKB 2 ICLK section 25.
Table 5.1 List of I/O Registers (Address Order) (4/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK
