Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 107 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
0008 6408h MPU Region-1 Start Page Number Register RSPAGE1 32 32 1 ICLK section 17.
0008 640Ch MPU Region-1 End Page Number Register REPAGE1 32 32 1 ICLK section 17.
0008 6410h MPU Region-2 Start Page Number Register RSPAGE2 32 32 1 ICLK section 17.
0008 6414h MPU Region-2 End Page Number Register REPAGE2 32 32 1 ICLK section 17.
0008 6418h MPU Region-3 Start Page Number Register RSPAGE3 32 32 1 ICLK section 17.
0008 641Ch MPU Region-3 End Page Number Register REPAGE3 32 32 1 ICLK section 17.
0008 6420h MPU Region-4 Start Page Number Register RSPAGE4 32 32 1 ICLK section 17.
0008 6424h MPU Region-4 End Page Number Register REPAGE4 32 32 1 ICLK section 17.
0008 6428h MPU Region-5 Start Page Number Register RSPAGE5 32 32 1 ICLK section 17.
0008 642Ch MPU Region-5 End Page Number Register REPAGE5 32 32 1 ICLK section 17.
0008 6430h MPU Region-6 Start Page Number Register RSPAGE6 32 32 1 ICLK section 17.
0008 6434h MPU Region-6 End Page Number Register REPAGE6 32 32 1 ICLK section 17.
0008 6438h MPU Region-7 Start Page Number Register RSPAGE7 32 32 1 ICLK section 17.
0008 643Ch MPU Region-7 End Page Number Register REPAGE7 32 32 1 ICLK section 17.
0008 6500h MPU Memory-Protection Enable Register MPEN 32 32 1 ICLK section 17.
0008 6504h MPU Background Access Control Register MPBAC 32 32 1 ICLK section 17.
0008 6508h MPU Memory-Protection Error Status-Clearing Register MPECLR 32 32 1 ICLK section 17.
0008 650Ch MPU Memory-Protection Error Status Register MPESTS 32 32 1 ICLK section 17.
0008 6514h MPU Data Memory-Protection Error Address Register MPDEA 32 32 1 ICLK section 17.
0008 6520h MPU Region Search Address Register MPSA 32 32 1 ICLK section 17.
0008 6524h MPU Region Search Operation Register MPOPS 16 16 1 ICLK section 17.
0008 6526h MPU Region Invalidation Operation Register MPOPI 16 16 1 ICLK section 17.
0008 6528h MPU Instruction-Hit Region Register MHITI 32 32 1 ICLK section 17.
0008 652Ch MPU Data-Hit Region Register MHITD 32 32 1 ICLK section 17.
0008 7010h
to
0008 70FFh
ICU Interrupt Request Register 016 to Interrupt Request
Register 255
IR016 to IR255 8 8 2 ICLK section 15.
0008 711Bh
to
0008 71FFh
ICU DTC Activation Enable Register 027 to DTC Activation
Enable Register 255
DTCER027 to
DTCER255
8 8 2 ICLK section 15.
0008 7202h
to
0008 721Fh
ICU Interrupt Request Enable Register 02 to Interrupt Request
Enable Register 1F
IER02 to IER1F 8 8 2 ICLK section 15.
0008 72E0h ICU Software Interrupt Generation Register SWINTR 8 8 2 ICLK section 15.
0008 72F0h ICU Fast Interrupt Set Register FIR 16 16 2 ICLK section 15.
0008 7300h
to
0008 73FFh
ICU Interrupt Source Priority Register 000 to Interrupt Source
Priority Register 255
IPR000 to
IPR255
8 8 2 ICLK section 15.
0008 7400h ICU DMAC Trigger Select Register 0 DMRSR0 8 8 2 ICLK section 15.
0008 7404h ICU DMAC Trigger Select Register 1 DMRSR1 8 8 2 ICLK section 15.
0008 7408h ICU DMAC Trigger Select Register 2 DMRSR2 8 8 2 ICLK section 15.
0008 740Ch ICU DMAC Trigger Select Register 3 DMRSR3 8 8 2 ICLK section 15.
0008 7500h
to
0008 7507h
ICU IRQ Control Register 0 to IRQ Control Register 7 IRQCR0 to
IRQCR7
8 8 2 ICLK section 15.
0008 7510h ICU IRQ Pin Digital Filter Enable Register 0 IRQFLTE0 8 8 2 ICLK section 15.
0008 7514h ICU IRQ Pin Digital Filter Setting Register 0 IRQFLTC0 16 16 2 ICLK section 15.
0008 7580h ICU Non-Maskable Interrupt Status Register NMISR 8 8 2 ICLK section 15.
0008 7581h ICU Non-Maskable Interrupt Enable Register NMIER 8 8 2 ICLK section 15.
0008 7582h ICU Non-Maskable Interrupt Status Clear Register NMICLR 8
8 2 ICLK section 15.
0008 7583h ICU NMI Pin Interrupt Control Register NMICR 8 8 2 ICLK section 15.
0008 7590h ICU NMI Pin Digital Filter Enable Register NMIFLTE 8 8 2 ICLK section 15.
0008 7594h ICU NMI Pin Digital Filter Setting Register NMIFLTC 8 8 2 ICLK section 15.
0008 8000h CMT Compare Match Timer Start Register 0 CMSTR0 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 8002h CMT0 Compare Match Timer Control Register CMCR 16 16 2 or 3 PCLKB 2 ICLK section 27.
0008 8004h CMT0 Compare Match Counter CMCNT 16 16 2 or 3 PCLKB 2 ICLK section 27.
Table 5.1 List of I/O Registers (Address Order) (3/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK

Renesas RX Series Specifications

General

Core	RXv1, RXv2, RXv3
Flash Memory	Up to 8 MB
RAM	Up to 1 MB
Operating Voltage	1.62V to 5.5V
Operating Temperature	-40°C to +85°C or +105°C
Package	BGA, LQFP
ADC Resolution	12-bit
DAC Resolution	12-bit
Communication Interfaces	SCI, SPI, I2C, USB, Ethernet, CAN
Architecture	32-bit
Security Features	Memory Protection Unit (MPU)
