RX23W Group 5. I/O Registers
0008 2004h DMAC0 DMA Destination Address Register DMDAR 32 32 2 ICLK section 18.
0008 2008h DMAC0 DMA Transfer Count Register DMCRA 32 32 2 ICLK section 18.
0008 200Ch DMAC0 DMA Block Transfer Count Register DMCRB 16 16 2 ICLK section 18.
0008 2010h DMAC0 DMA Transfer Mode Register DMTMD 16 16 2 ICLK section 18.
0008 2013h DMAC0 DMA Interrupt Setting Register DMINT 8 8 2 ICLK section 18.
0008 2014h DMAC0 DMA Address Mode Register DMAMD 16 16 2 ICLK section 18.
0008 2018h DMAC0 DMA Offset Register DMOFR 32 32 2 ICLK section 18.
0008 201Ch DMAC0 DMA Transfer Enable Register DMCNT 8 8 2 ICLK section 18.
0008 201Dh DMAC0 DMA Software Start Register DMREQ 8 8 2 ICLK section 18.
0008 201Eh DMAC0 DMA Status Register DMSTS 8 8 2 ICLK section 18.
0008 201Fh DMAC0 DMA Activation Source Flag Control Register DMCSL 8 8 2 ICLK section 18.
0008 2040h DMAC1 DMA Source Address Register DMSAR 32 32 2 ICLK section 18.
0008 2044h DMAC1 DMA Destination Address Register DMDAR 32 32 2 ICLK section 18.
0008 2048h DMAC1 DMA Transfer Count Register DMCRA 32 32 2 ICLK section 18.
0008 204Ch DMAC1 DMA Block Transfer Count Register DMCRB 16 16 2 ICLK section 18.
0008 2050h DMAC1 DMA Transfer Mode Register DMTMD 16 16 2 ICLK section 18.
0008 2053h DMAC1 DMA Interrupt Setting Register DMINT 8 8 2 ICLK section 18.
0008 2054h DMAC1 DMA Address Mode Register DMAMD 16 16 2 ICLK section 18.
0008 205Ch DMAC1 DMA Transfer Enable Register DMCNT 8 8 2 ICLK section 18.
0008 205Dh DMAC1 DMA Software Start Register DMREQ 8 8 2 ICLK section 18.
0008 205Eh DMAC1 DMA Status Register DMSTS 8 8 2 ICLK section 18.
0008 205Fh DMAC1 DMA Activation Source Flag Control Register DMCSL 8 8 2 ICLK section 18.
0008 2080h DMAC2 DMA Source Address Register DMSAR 32 32 2 ICLK section 18.
0008 2084h DMAC2 DMA Destination Address Register DMDAR 32 32 2 ICLK section 18.
0008 2088h DMAC2 DMA Transfer Count Register DMCRA 32 32 2 ICLK section 18.
0008 208Ch DMAC2 DMA Block Transfer Count Register DMCRB 16 16 2 ICLK section 18.
0008 2090h DMAC2 DMA Transfer Mode Register DMTMD 16 16 2 ICLK section 18.
0008 2093h DMAC2 DMA Interrupt Setting Register DMINT 8 8 2 ICLK section 18.
0008 2094h DMAC2 DMA Address Mode Register DMAMD 16 16 2 ICLK section 18.
0008 209Ch DMAC2 DMA Transfer Enable Register DMCNT 8 8 2 ICLK section 18.
0008 209Dh DMAC2 DMA Software Start Register DMREQ 8 8 2 ICLK section 18.
0008 209Eh DMAC2 DMA Status Register DMSTS 8 8 2 ICLK section 18.
0008 209Fh DMAC2 DMA Activation Source Flag Control Register DMCSL 8 8 2 ICLK section 18.
0008 20C0h DMAC3 DMA Source Address Register DMSAR 32 32 2 ICLK section 18.
0008 20C4h DMAC3 DMA Destination Address Register DMDAR 32 32 2 ICLK section 18.
0008 20C8h DMAC3 DMA Transfer Count Register DMCRA 32 32 2 ICLK section 18.
0008 20CCh DMAC3 DMA Block Transfer Count Register DMCRB 16 16 2 ICLK section 18.
0008 20D0h DMAC3 DMA Transfer Mode Register DMTMD 16 16 2 ICLK section 18.
0008 20D3h DMAC3 DMA Interrupt Setting Register DMINT 8 8 2 ICLK section 18.
0008 20D4h DMAC3 DMA Address Mode Register DMAMD 16 16 2 ICLK section 18.
0008 20DCh DMAC3 DMA Transfer Enable Register DMCNT 8 8 2 ICLK section 18.
0008 20DDh DMAC3 DMA Software Start Register DMREQ 8 8 2 ICLK section 18.
0008 20DEh DMAC3 DMA Status Register DMSTS 8 8 2 ICLK section 18.
0008 20DFh DMAC3 DMA Activation Source Flag Control Register DMCSL 8 8 2 ICLK section 18.
0008 2200h DMAC DMA Module Activation Register DMAST 8 8 2 ICLK section 18.
0008 2400h DTC DTC Control Register DTCCR 8 8 2 ICLK section 19.
0008 2404h DTC DTC Vector Base Register DTCVBR 32 32 2 ICLK section 19.
0008 2408h DTC DTC Address Mode Register DTCADMOD 8 8 2 ICLK section 19.
0008 240Ch DTC DTC Module Start Register DTCST 8 8 2 ICLK section 19.
0008 240Eh DTC DTC Status Register DTCSTS 16 16 2 ICLK section 19.
0008 6400h MPU Region-0 Start Page Number Register RSPAGE0 32 32 1 ICLK section 17.
0008 6404h MPU Region-0 End Page Number Register REPAGE0 32 32 1 ICLK section 17.
Table 5.1 List of I/O Registers (Address Order) (2/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK
