Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 117 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
0008 B119h ELC Event Link Setting Register 24 ELSR24 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B11Ah ELC Event Link Setting Register 25 ELSR25 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B11Bh ELC Event Link Setting Register 26 ELSR26 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B11Ch ELC Event Link Setting Register 27 ELSR27 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B11Dh ELC Event Link Setting Register 28 ELSR28 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B11Eh ELC Event Link Setting Register 29 ELSR29 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B11Fh ELC Event Link Option Setting Register A ELOPA 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B120h ELC Event Link Option Setting Register B ELOPB 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B121h ELC Event Link Option Setting Register C ELOPC 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B122h ELC Event Link Option Setting Register D ELOPD 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B123h ELC Port Group Setting Register 1 PGR1 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B124h ELC Port Group Setting Register 2 PGR2 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B125h ELC Port Group Control Register 1 PGC1 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B126h ELC Port Group Control Register 2 PGC2 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B127h ELC Port Buffer Register 1 PDBF1 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B128h ELC Port Buffer Register 2 PDBF2 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B129h ELC Event Link Port Setting Register 0 PEL0 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B12Ah ELC Event Link Port Setting Register 1 PEL1 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B12Bh ELC Event Link Port Setting Register 2 PEL2 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B12Ch ELC Event Link Port Setting Register 3 PEL3 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B12Dh ELC Event Link Software Event Generation Register ELSEGR 8 8 2 or 3 PCLKB 2 ICLK section 20.
0008 B300h SCI12 Serial Mode Register SMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B300h SMCI12 Serial Mode Register SMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B301h SCI12 Bit Rate Register BRR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B302h SCI12 Serial Control Register SCR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B302h SMCI12 Serial Control Register SCR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B303h SCI12 Transmit Data Register TDR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B304h SCI12 Serial Status Register SSR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B304h SMCI12 Serial Status Register SSR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B305h SCI12 Receive Data Register RDR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B306h SCI12 Smart Card Mode Register SCMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B306h SMCI12 Smart Card Mode Register SCMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B307h SCI12 Serial Extended Mode Register SEMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B308h SCI12 Noise Filter Setting Register SNFR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B309h SCI12 I
2
C Mode Register 1 SIMR1 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B30Ah SCI12 I
2
C Mode Register 2 SIMR2 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B30Bh SCI12 I
2
C Mode Register 3 SIMR3 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B30Ch SCI12 I
2
C Status Register SISR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B30Dh SCI12 SPI Mode Register SPMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B30Eh SCI12 Transmit Data Register HL TDRHL 16 16 4 or 5 PCLKB 2 ICLK section 33.
0008 B30Eh SCI12 Transmit Data Register H TDRH 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B30Fh SCI12 Transmit Data Register L TDRL 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B310h SCI12 Receive Data Register HL RDRHL 16 16 4 or 5 PCLKB 2 ICLK section 33.
0008 B310h SCI12 Receive Data Register H RDRH 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B311h SCI12 Receive Data Register L RDRL 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B312h SCI12 Modulation Duty Register MDDR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B320h SCI12 Extended Serial Module Enable Register ESMER 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B321h SCI12 Control Register 0 CR0 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B322h SCI12 Control Register 1 CR1 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B323h SCI12 Control Register 2 CR2 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B324h SCI12 Control Register 3 CR3 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B325h SCI12 Port Control Register PCR 8 8 2 or 3 PCLKB 2 ICLK section 33.
Table 5.1 List of I/O Registers (Address Order) (13/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK
