Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 118 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
0008 B326h SCI12 Interrupt Control Register ICR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B327h SCI12 Status Register STR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B328h SCI12 Status Clear Register STCR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B329h SCI12 Control Field 0 Data Register CF0DR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B32Ah SCI12 Control Field 0 Compare Enable Register CF0CR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B32Bh SCI12 Control Field 0 Receive Data Register CF0RR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B32Ch SCI12 Primary Control Field 1 Data Register PCF1DR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B32Dh SCI12 Secondary Control Field 1 Data Register SCF1DR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B32Eh SCI12 Control Field 1 Compare Enable Register CF1CR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B32Fh SCI12 Control Field 1 Receive Data Register CF1RR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B330h SCI12 Timer Control Register TCR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B331h SCI12 Timer Mode Register TMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B332h SCI12 Timer Prescaler Register TPRE 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 B333h SCI12 Timer Count Register TCNT 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 C000h PORT0 Port Direction Register PDR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C001h PORT1 Port Direction Register PDR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C002h PORT2 Port Direction Register PDR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C003h PORT3 Port Direction Register PDR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C004h PORT4 Port Direction Register PDR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C00Bh PORTB Port Direction Register PDR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C00Ch PORTC Port Direction Register PDR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C00Dh PORTD Port Direction Register PDR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C00Eh PORTE Port Direction Register PDR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C012h PORTJ Port Direction Register PDR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C020h PORT0 Port Output Data Register PODR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C021h PORT1 Port Output Data Register PODR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C022h PORT2 Port Output Data Register PODR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C023h PORT3 Port Output Data Register PODR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C024h PORT4 Port Output Data Register PODR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C02Bh PORTB Port Output Data Register PODR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C02Ch PORTC Port Output Data Register PODR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C02Dh PORTD Port Output Data Register PODR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C02Eh PORTE Port Output Data Register PODR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C032h PORTJ Port Output Data Register PODR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C040h PORT0 Port Input Data Register PIDR 8 8 3 or 4 PCLKB 3 ICLK section 21.
0008 C041h PORT1 Port Input Data Register PIDR 8 8 3 or 4 PCLKB 3 ICLK section 21.
0008 C042h PORT2 Port Input Data Register PIDR 8 8 3 or 4 PCLKB 3 ICLK section 21.
0008 C043h PORT3 Port Input Data Register PIDR 8 8 3 or 4 PCLKB 3 ICLK section 21.
0008 C044h PORT4 Port Input Data Register PIDR 8 8 3 or 4 PCLKB 3 ICLK section 21.
0008 C04Bh PORTB Port Input Data Register PIDR 8 8 3 or 4 PCLKB 3 ICLK section 21.
0008 C04Ch PORTC Port Input Data Register PIDR 8 8 3 or 4 PCLKB 3 ICLK section 21.
0008 C04Dh PORTD Port Input Data Register PIDR 8 8 3 or 4 PCLKB 3 ICLK section 21.
0008 C04Eh PORTE Port Input Data Register PIDR 8 8 3 or 4 PCLKB 3 ICLK section 21.
0008 C052h PORTJ Port Input Data Register PIDR 8 8 3 or 4 PCLKB 3 ICLK section 21.
0008 C060h PORT0 Port Mode Register PMR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C061h PORT1 Port Mode Register PMR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C062h PORT2 Port Mode Register PMR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C063h PORT3 Port Mode Register PMR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C064h PORT4 Port Mode Register PMR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C06Bh PORTB Port Mode Register PMR 8 8 2 or 3 PCLKB 2 ICLK section
21.
000
8 C06Ch PORTC Port Mode Register PMR 8 8 2 or 3 PCLKB 2 ICLK section 21.
0008 C06Dh PORTD Port Mode Register PMR 8 8 2 or 3 PCLKB 2 ICLK section 21.
Table 5.1 List of I/O Registers (Address Order) (14/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK
